ArqCOM - CAD Earth v4.1.2 for Autocad 2007 to 2015

轻松导入/导出图像，物体和地形在谷歌地球和其他主流CAD程序之间的插件。

Easily import/export images, objects and terrain meshes between Google Earth™ and major CAD programs

Preview position of selected drawing entities in a map

New in version 4.1. Added ability to preview position of selected drawing entities in a map when selecting a coordinate system to georeference a drawing. Drawing entities can be moved, scaled or rotated in the map until they match the site.

Process images up to 10x faster

Process images up to 10x faster from different providers (Google, Bing, Yahoo, Ovi) in satellite, map or hybrid image mode in normal, medium, high or highest resolution.

Map Control for drawing entities

New map control where you can preview drawing entities in the real world. You can move, scale and rotate reference entities in real time until they match the exact location.

Commands to georeference a drawing

Avoid misplaced images or objects using new commands to georeference a drawing by locating entities in a map or selecting two points and typing their latitude/longitude coordinates.

Optimized “import terrain mesh” command

The command to import terrain mesh from Google Earth has been greatly optimized for speed and performance.

Insert georeferenced images

If you have image files with the corresponding world file containing spatial data information you can accurately place them in the drawing automatically applying XY scale and translation transformations.

Get contour lines, profiles and sections from Google Earth™ (Plus version).

You can create a terrain configuration mesh inside an existing closed polyline or along a polyline path calculating point elevations from Google Earth™. By specifying the origin point, rotation angle and distance between rows and columns, the mesh density and precision can be adjusted. The resulting mesh can be processed to obtain contour lines, dynamic profile and section drawings, complete with annotations.

Export CAD screenshots to Google Earth™

Users can export CAD drawings to Google Earth™ as image overlays. Those image captures can be in full color, grayscale or B&W, and are compatible as major image formats (BMP, JPEG, TIFF, PNG, GIF). Background color can be completely transparent or customized to your desired color. Screenshots can be also taken in sections to increase the quality of the final image resolution.

Export CAD objects to Google Earth™

Lines, polylines, arcs, circles, and points can be exported to Google Earth™ as polygons, routes or placemarks. Object line thickness, outline, fill color and opacity can also be adjusted. Curve smoothness can be controlled by specifying the maximum segment length and deflection angle. The placemark name, description, scale and icon can also be customized to your needs.
