MR1升级补丁，需要先安装：

Siemens PLM NX 10.0.0.24 x64

或

Siemens PLM NX 10.0 Linux

Siemens PLM NX 10.0 MR1 Update | 3.2 Gb

Siemens PLM Software, computer software company specializing in 3D & 2D Product Lifecycle Management (PLM) software, has released an MR1 for Siemens PLM NX 10.0, new version fully integrated computer-aided design, manufacturing and engineering analysis (CAD/CAM/CAE) solution.

The latest version of Siemens’ NX software (NX 10) includes new capabilities that deliver enhanced product development flexibility and up to three times higher productivity. New tools like the 2D concept development solution make it easier and faster to create designs, while enhancements to NX Realize Shape software, a fully integrated sub-division modelling environment, give designers more flexibility to produce unique shapes. A new optional touch-enabled interface provides expanded access to the full design capabilities of NX. And tighter integration to product lifecycle management (PLM) software, through Siemens’ Active Workspace environment, reduces the amount of time spent searching for product information. NX 10 also includes multiple enhancements throughout the integrated computer-aided design, manufacturing and engineering (CAD/CAM/CAE) solution.

Fixed Problem Reports:

1127721 Define Deformable Part option disappears from menu switching to Routing app

1127732 Routing move part does not give orientation options if part is an assembly

1127821 Wrong tool path computation in PLANAR PROFILE

1127824 Law Extension Miter Method

1127845 Sketch coincident constraint snaps to opposite end point of edge than selected

1127927 Curve Length Bug in NX 9.0.3

1127954 Error - Invalid view sequence number found, creating Stock Offset Spline Point

1127974 Not able to open Partfile (last stored in NX 9.0.1) in NX 9.0.2.5 D3, 04Aug14

1127978 Wrong Z direction of weld point created by existing points

1128175 NXOpen can't get Dimension Hole and Shaft tol values from FitSymbolsAndLimits

1128277 Editing of spline path created Pre NX 9.0 takes a long time

1128288 Bad file after postprocess with sim08_mill_5ax_tnc_mm.pui

1128489 THBCS21 gives 5K error relative to analytical result

1128515 Define Deformable Part option disappears from menu switching to Routing App

1128678 Cannot add drawing for undercut blank due to missing EW_COMPONENT_TYPE

1128688 Show exact fails on JT file

1128705 Electrode Design Blank increases undercut REF_Z value on each Position Update

1128757 Multiple bodies in global shaping results in scattered sheet bodies

1128761 Studio spline in expand view

1128833 CAM: Performance Problem after upgrade to NX 8.5.3 MP6

1128970 'previous_next mode_iteration' command does not update streamline paths

1129052 Reference Text Attribute does not update after revise

1129058 Flow velocity transient results animation does not update streamline paths

1129167 Strange behavior during edit reusable components

1129174 Placement Solutions are grayed out when trying to Move Part in Routing

1129175 COM Error 80010100 while creating parts from complex part family

1129227 Colors on faces are not preserved during Feature Playback

1129234 Law extension surface doesn't meet quality

1129540 Sketch solver can not solve a dimension at a given size

1129622 Dimensions disappear after update, or are just shown during update

1129661 Milling toolpaths go out of date when creating a mill contour operation

1129704 Wrong dimension value in view break

1129709 Tool axis loses position when operation copied

1129787 Internal error: attempt to access the tag of non-tagged object

1793635 Poor sweep regeneration performance

1875433 Open whole assembly in NX 7.5 - opens only one level at time

1891527 Getting incorrect retracts for some fonts in Planar Text operation

1891964 NX Mold Wizard Work Piece command not working as described in MT10420

1900620 Retract Move damaged the Workpiece but NX does not realize this

1902449 Analyze Formability Unfold Side Control missing.........and more

About Siemens AG

Siemens AG is a global technology powerhouse that has stood for engineering excellence, innovation, quality, reliability and internationality for more than 165 years. The company is active in more than 200 countries, focusing on the areas of electrification, automation and digitalization. One of the world’s largest producers of energy-efficient, resource-saving technologies, Siemens is No. 1 in offshore wind turbine construction, a leading supplier of combined cycle turbines for power generation, a leading provider of power transmission solutions and a pioneer in infrastructure solutions and automation and software solutions for industry. The company is also a leading supplier of medical imaging equipment – such as computed tomography and magnetic resonance imaging systems – and a leader in laboratory diagnostics as well as clinical IT.

Name: Siemens PLM

Version: NX (64bit) 10.0.1.4 (10.0 MR1) Update

Interface: multilanguage

OS: Windows / Linux

System Requirements: Siemens PLM NX 10.0.0

Size: 3.2 Gb

Special Thanks Team-SolidSQUAD
