Delcam PowerSHAPE 2016 SPx Update | 600 mb

One of the world's leading suppliers of advanced CAD/CAM solutions, Delcam, has released update of PowerSHAPE 2016 Pro CAD for CAM system, for modelling, manufacture and reverse engineering. The new release includes improvements in direct modelling, surface modelling and reverse engineering, plus support for data from Creaform HandySCAN hand-held scanners.

PowerSHAPE Pro has often been lauded for the strengths it has always had on its surface-modelling capabilities. These capabilities have been further improved with new dynamic point editing. Multiple points, either along a single curve or picked from multiple curves, can now be selected and moved, with real-time updating of the model. This makes styling of free-form shapes easier and quicker, and also speeds up modelling for manufacture tasks like removing undercuts from tooling designs.

PowerSHAPE Pro has also been made faster and easier in the ability to morph complete models into a new shape. One key application for this option is in compensating for springback in press tools or warpage in moulded products. The user can alter CAD directly based on scan data from a sample part collected as a point cloud or as a triangle mesh, with a choice between either updating the CAD model of the part to match the as-produced item or adjusting the tooling design so that it can produce parts matching the original CAD data.

Another important application of morphing is in updating parts that need to be repaired but that have changed their shape during use. A typical example is turbine blades that have been distorted by heat so that their shape no longer matches the CAD data used for their manufacture. Again, the original CAD data can be adjusted to match scan data captured from the actual part.

The main enhancement to PowerSHAPE Pro’s reverse engineering functionality is a more automated method for capturing cross-sections through a mesh. The software now fits lines and fillets to the cross-section where it can, with the user able to control the tolerance used. This method uses the mesh as a guide instead of treating it as exact geometry with the priority of capturing the design intent rather than ensuring a precise fit to the scan data.

About Delcam plc

Delcam is a world-leading developer and supplier of advanced CADCAM software, with more than 35,000 customers in over 80 countries. These clients vary from global names like Nike, Boeing and Mattel to small start-ups and individual craftsmen. Founded 30 years ago, we are the largest developer of product development software in the UK, with subsidiaries in Europe, America and Asia. Our global success has been recognised with many awards, including three Queen’s Awards for Enterprise in the last six years.

Name: Delcam PowerSHAPE

Version: (64bit) 2016 SPx

Interface: multilanguage

OS: Windows 7even / 8

System Requirements: Delcam PowerShape 2016

SP6
