SolidWorks是全球领先的3D软件进行产品开发和设计。 开始创建生产就绪的零件和组件，以及材料的详细图纸及票据。 在这个过程中，笔者加布里埃尔科贝特显示了如何创建二维草图，这将成为基础为您的3D模型。 您将使用拉伸和旋转工具，可以将二维草图转换为3D零部件，然后创建一个具有扫描和阁楼更复杂的几何图形。 然后学习如何使用剪切功能来去除材料和形状的零件，并使用镜像，图案和缩放修改的部分。 接下来，将结合部分为可移动的组件和部件。 最后，您将创建准确注明图纸，完成与中有关最终的零件和组件。

持续时间：6小时20分

SolidWorks 2014 Essential Training | 1.23 GB

Duration: 6h 20m | Video: AVC (.mp4) 960x540 30fps | Audio: AAC 48KHz 1ch

Genre: eLearning | Level: Intermediate | Duration: Dec 09, 2013

SolidWorks is the world leader in 3D software for product development and design. Start creating manufacturing-ready parts and assemblies, as well as detailed drawings and bills of materials. In this course, author Gabriel Corbett shows how to create 2D sketches that will become the basis for your 3D models. You'll use the Extrude and Revolve tools to turn 2D sketches into 3D parts, then create more complex geometry with sweep and lofts. Then learn how to use the cut features to remove material and shape parts, and use mirroring, patterning, and scaling to modify parts. Next, you'll combine parts into movable assemblies and subassemblies. Finally, you'll create accurately annotated drawings, complete with itemized bills of materials that relate the final parts and assemblies to a manufacturer.

Topics include:

Creating your first part

Starting a new sketch

Adding and removing relationships and dimensions

Sketching polygons

Creating offset geometry

Moving, copying, and rotating elements

Working with planes, axes, and the coordinate system

Using Revolve and Loft to create 3D objects

Trimming with the Revolve, Loft, and Sweep cuts

Creating smooth and angled corners with fillets and chamfers

Designing with sketch blocks

Working with subassemblies

Creating threaded parts

Integrating Excel to manage design tables

Adding dimension notations to a drawing

Rendering an image of a part or assembly
