Cadence Allegro and OrCAD (Including ADW) 17.00.002 hotfix | 688.3 mb

Cadence Design Systems, Inc., a leader in global electronic design innovation, has released the hotfix of Cadence Allegro and OrCAD 17.0 design solution with new features, enhanced customization capabilities, and simulation performance improvements that provide customers a shorter, more predictable path to product creation.

17.0, as with all major dot zero releases, contains a number of architectural changes that will have an adoption overhead for customers, such as 64Bit only operating system, database changes that require a database update and a new library padstack structure. Through discussions with customers around the world we have learned that a 2015 mandatory update to 17.0 may require more preparation at some customer sites. Therefore the OrCAD and Allegro management team have decided to create and release a new feature packed 2015 version of 16.6 (16.6-2015) that will deliver new OrCAD and Allegro products as well as new functionality tiering of the OrCAD and Allegro base PCB products and pull forward some of the key 17.0 features such as Shape Edit application mode. This new 16.6-2015 release is being planned for June’2015. Therefore 17.0 is being re-positioned as a limited access Early Adopter Program (EAP) release, available and supported for production work for those companies using Allegro who want/need to move to a 64Bit operating system and/or begin to take advantage of the new database Padstack support. With the new feature-rich 16.6-2015 release we do not expect a large number of customers will want to upgrade to 17.0.

DATE: 05-01-2015 HOTFIX VERSION: 002

===============================================================================================

CCRID PRODUCT PRODUCTLEVEL2 TITLE

===============================================================================================

1315048 ALLEGRO_EDITOR INTERFACES IPC2581 translation inconsistency on negative layer

1362745 CONSTRAINT_MGR OTHER Allegro PCB Editor crashes on opening Constraint Manager with any design

1373412 ALLEGRO_EDITOR GRAPHICS SigXP Print Canvas : Via model seems to be filled by black Via box.

1376765 CONSTRAINT_MGR ANALYSIS Setup/Hold spreadsheet lists only one pin pair

1399646 ASI_SI OTHER Should be able to run mbs2brd with SI/PI base licenses

1400215 SIG_INTEGRITY REPORTS cross talk failure on certain nets in PCB SI 16.6

1400302 ALLEGRO_EDITOR MANUFACT Copper Thieving is working differently in SPB16.6 as compared to SPB16.5

1400755 ALLEGRO_EDITOR SHAPE Updating the shapes on the attached deisgn causes a short to a pad.

1400813 ALLEGRO_EDITOR SHAPE PCB Editor crashes when you delete islands from all the layers and save the board

1404174 SIP_LAYOUT OTHER Creating bounding shapes generates incorrect shapes and DRCs

1404184 ALLEGRO_EDITOR INTERFACES Step package mapping - Save is disabled for certain symbol

1406457 ALLEGRO_EDITOR SCRIPTS Unable to launch allegro.exe -orcad after update hotfix 046

1407123 ALLEGRO_EDITOR OTHER Lines with zero line width are not being printed in PDF format

1407483 ALLEGRO_EDITOR REFRESH The 'refresh symbol' command creates an unrouted connection in a fully routed design

1408072 SIP_LAYOUT OTHER Net assignment for a BGA component fails on running the File - Import - Netlist-in wizard command.

1410857 ALLEGRO_EDITOR DRC_CONSTR Diff Pair Uncoupled length DRC gives different results in SPB16.3, SPB16.5, and SPB16.6.

1413235 ALLEGRO_EDITOR INTERACTIV Find by Query with Via Structures: GUI freeze
