Siemens 西门子公司宣布发行Solid Edge ST8最新版本！

Solid Edge是一个行业领先的机械设计系统，它为三维数字原型的创建和管理提供了出色的工具。通过出色的核心建模和过程工作流、对特定行业需求的独特关注、以及全面集成的设计管理，Solid Edge为设计项目提供了一个精准设计、不出错的设计解决方案。有了Solid Edge建模和装配工具，您的工程团队能够很容易地开发一系列产品 – 从单一零件到由数千个部件组成的装配。定制的命令和结构化的工作流加快了特定行业的零件特征的设计，同时通过在装配模型中设计、分析和修改零件，您可以确保这些零件的拟合度和功能达到要求。采用Solid Edge，您每次都能在第一次生产出正确的产品。

在主流机械设计系统中，只有Solid Edge才把设计管理功能与设计人员每天使用的CAD工具完美地结合起来。 Solid Edge为客户提供了多种可扩展的产品数据管理解决方案，因此设计创建好之后，他们就能快速管理这些设计。通过用实用的工具来进行受控状态下的协同，有助于更好地协调设计团队活动，避免因沟通不当造成错误。

通过利用Solid Edge的一系列模块和集成解决方案，他们率先从CAD行业中功能最强的创新中收益，率先完成了设计，并且率先向市场提供了无差错产品。

产品与过程复杂性是制造组织面临的越来越大的问题，因此全球已有数千家企业采用了Solid Edge，将其作为解决这一复杂性的工具。通过利用Solid Edge的一系列模块和集成解决方案，他们率先从CAD行业中功能最强的创新中收益，率先完成了设计，并且率先向市场提供了无差错产品。

通过出色的核心建模和过程工作流，以特定行业的需要为中心，并且提供全面集成的设计管理，Solid Edge为项目提供了一个没有错误并且准确的设计解决方案。

Siemens Solid Edge ST8 v108.00.00.91 (x64) | 4.99 GB

Solid Edge ST8 - the most full-featured hybrid 2D / 3D CAD system that uses synchronous technology to accelerate the process of designing and editing, as well as enhanced support for re-use of imported geometry. Solid Edge is a key component of the portfolio Velocity Series ™, and has excellent tools for modeling parts and assemblies, design drawings, transparent data management, built-in finite element analysis, which helps to cope with the growing complexity of future product

The new version of Solid Edge ST8 offers enhanced functionality based on synchronous technology, which greatly speeds up the process of product design, easy modification, importation and use data created in different CAD systems. The latest version includes improvements in the finite element analysis, data management, design, and more than a thousand changes to specific users.

Implementing the concept of synchronous technology company Siemens PLM Software has expanded the possibility of using synchronous technology throughout the system. Furthermore implemented in previous versions support for modeling components and sheet metal, synchronous model can be applied directly to the assembly - for example, when designing pipelines, farms, wiring and other products. First introduced the associativity between synchronous parts, which allows the user to create and modify his plan before, during or at the end of the design process of the assembly.

Solid Edge ST8 provides an opportunity to work with both synchronous and conventional (ordered in the tree construction) design elements in a single integrated design environment. Users can use synchronous design elements to accelerate the process of designing and flexible editing models, and elements of the tree building - for the design of molded parts and components, obtained by machining. Elements of the tree construction in the existing models can be selectively converted into synchronous, which gives the designer greater flexibility and ease of use of the system.

As the number of enterprises making the transition from other 3D systems to Solid Edge and take advantage of synchronous technology is growing, there was a possibility of combining 2D drawings with existing 3D models - another way to improve performance. Technological dimensions on 2D drawings can now be automatically transferred to the corresponding imported 3D model. Obtained as a result of "manufacturing» 3D dimensions can be immediately edited and imported 3D model is changed simultaneously by synchronous technology.

Solid Edge ST8 has an application for finite element analysis, including new types of loads - torque and load in a cylindrical support user-defined constraints and new ways of connecting parts in assemblies such as bolted connections and joints for sheet metal edges. Tools simplify the model allows you to quickly calculate the results, and advanced visualization tools - see the model from the inside. The model can be adjusted as with synchronous technology, and with the use of wood construction. Solid Edge provides the control models of parts and assemblies in the early stages of design, which reduces the time-to-market and cost of prototyping.

The Solid Edge ST8 - thousands of specific improvements to customers, which further increases the impact of this product at all stages of product design. New features have appeared in different modules, including the simulation of sheet metal, pipes and trusses, build management tools and drafting. Improvements in the design environment sheet metal includes new types of closure angles, element symbols etched details and a different geometry, as well as technological elements in the unfolding of sheet parts such as shipping ears. Solid Edge continues to raise the bar in drawing creation in which you can now transfer all the technological dimensions and notations indicate parts in the assembly, and even provide details of different colors of lines in the drawing, by borrowing them from the 3D model. New "international" drawings allow you to use different character sets in different languages in a single drawing or a balloon. The streamlined user interface includes a fully customizable radial menu, which reduces the number of mouse movements. Transparent dialogue management design elements and details, as well as dialogues teams reduced size provide the largest area of graphic workspace.
