SoMachine V4 - 面向设备制造商们的全面解决方案

SoMachine软件是一款集成Vijeo-Designer软件的开放、高效的专业软件解决方案。它同时集成用于运动控制设备的配置和传送工具。它具备符合IEC 61131-3标准的语言功能,集成现场总线配置程序、专家诊断功能和故障调试功能,以及维护和可视化等多重功能。优势:扩展丰富,灵巧应用,高性价比,稳定可靠。

SoMachine Basic- 使用简便,上手快捷的编程软件

界面友好,上手快捷:简化的界面设计,让您轻松找到所需信息提供多种功能,提升工作效率。

SoMachine软件可以让您在施耐德电气灵活可扩展的控制平台上完成所有元器件的编程、调试,是面向设备制造商们的全面解决方案,帮助您根据每个设备的要求优化自动控制解决方案。

SoMachine Basic- SoMachine Basic软件界面设计新颖,极易上手, 缩短您项目开发周期,软件导航简单直观。

适用于施耐德OEM PLC、HMI、Motion、VSD 的软件平台

SoMachine V4 - 灵活可扩展的控制平台包括:

控制器:

- HMI控制器:HMI SCU、XBT GC、XBT GT/GK

- Modicon可编程控制器:M208、M218、M238、M241、M251及M258

- 运动控制器:Modicon LMC 058

- 集成式控制卡:Altivar IMC

I/O模块系列:

- Modicon模块:提供TM2、TM3、TM4、TM5及TM7等模块

HMI:

- 小型控制面板MagelisTM STO/STU

-  高级控制面板MagelisTTM GH/GK/GT

- 最先进控制面板MagelisTM GTO

SoMachine Basic-用于ModiconM221一体型及书本型可编程控制器的项目开发

Schneider Electric SoMachine 4.1 SP1.2 | 8.7 Gb

Schneider Electric, the global specialist in energy management, has released update (SP1.2) of Electric SoMachine 4.1 its a unique solution software for developing, configuring, and commissioning the entire machine in a single software environment, including logic, motion control, HMI, and related network automation functions.

Thanks to many predefined templates in SoMachine you save engineering time by applying complete libraries or even a new machine module.

- Improve efficiency with flexible and scalable performance: Replace a controller with another one, while retaining the logic and the configuration. Several versions of SoMachine can run in parallel in a system to help ensure compatibility

- All-embedded: Vijeo-Designer, configuring and commissioning tool for motion control devices, the IEC 61131-3 languages, integrated fieldbus configurators, expert diagnostics and debugging, multiple capabilities for maintenance and visualization including web-visualization and tested, validated, documented, and supported expert application libraries dedicated to numerous applications.

- Simplify integration and maintenance: As soon as the machine starts working SoMachine provides you with all relevant diagnostics data on PC, HMI or even on your mobile device

One single software to program your entire machine

- Controllers: Logic controllers Modicon M238, M241, M251 and M258, Motion controllers Modicon LMC058 and LMC078, PacDrive LMC Eco and Pro series/all models, HMI controllers Magelis SCU, Magelis XBTGC and XBTGT/GK and Drive controllers Altivar IMC

- I/O modules: Modicon TM2, TM3, TM5 and TM7

- HMI: Magelis STO/STU Small Panels, Magelis GH/Magelis GK/Magelis GT Advanced Panels and Magelis GTO Optimum Advanced Panels

SoMachine Motion is the single entry point for the engineering process basing on PacDrive 3 (Link to PacDrive/ID 7590). The workbench is consisting of all required tools for the complete engineering process, including commissioning and diagnostics. The necessary tools are available once SoMachine Motion is installed on the user´s Windows PC.

- Ideally suited for managing mechatronic and motion centric design projects that integrate the mechanical, hardware and electronics development into an interdisciplinary process

- Programming/path generation for machines with embedded robots, transformation modules for PacDrive kinematics, user-specific and third-party kinematics as well

- Integrated test environment

- Tools for motion design, motion system design, drive selection, program development, functional safety, HMI applications, simulation, commissioning, diagnostics and assistant tools for data handling - all in a single package

- Intuitive user interface modelled on familiar Office and Windows programs

Program any functionality of your machine as easy and as fast as possible and discover SoMachine Basic - Schneider Electric’s lightweight software solution dedicated to our Modicon M221 controller. The intuitive automation of simple machines within just four steps: Hardware configuration, programming, display configuration, commissioning – and your machine is running! SoMachine allows a flexible and scalable usage of controllers in the SoMachine context: it is easy to integrate the M221 logic controllers from SoMachine Basic into a SoMachine project. SoMachine Basic is available as free download

SoMachine is a MachineStruxure software. The NEXT generation of MachineStruxure™ from Schneider Electric is an intuitive solution for machine automation with all the features and functions you need to build machines that will improve your bottom line. From design and development, to commissioning and maintenance, MachineStruxure is a complete machine building solution with benefits all through the machine life cycle.

Release Notes SoMachine 4.1 SP1.2: ReleaseNotes.EN-SoMachineV4.1SP1.2_4.1.0.2_15.07.09.01.pdf

Schneider Electric SoMachine 4.1 SP1.2的图片2

About Schneider Electric

As a global specialist in energy management with operations in more than 100 countries, Schneider Electric offers integrated solutions across multiple market segments, including leadership positions in Utilities & Infrastructures, Industries & Machine Manufacturers, Non-residential Buildings, Data Centres & Networks and in Residential. Focused on making energy safe, reliable, efficient, productive and green, the Group’s 130,000 plus employees achieved sales of 22.4 billion euros in 2011, through an active commitment to help individuals and organizations make the most of their energy.

Name: Schneider Electric SoMachine 4.1 SP1.2

Version: 4.1 SP1.2 Build 15.07.09.01

Interface: multilanguage

OS: Windows 7even / 8.1

Size: 8.7 Gb
