SAMCEF Field是一个通用的前后处理器,是集成结构线性非线性分析、热力耦合分析、基于有限元的多体动力学仿真和多物理场求解的CAE平台。
专业便捷的有限元前后处理平台SAMCEF Field是一个完整的综合前后处理环境,其功能包括建模、线性与非线性结构分析的驱动和管理,是CAD到CAE的连接桥梁。作为一个开放式的环境,SAMCEF Field通过非常直观的导航功能,为用户进行机构和结构的设计和仿真分析提供了一个必要的工具。
SAMCEF Field与SAMCEF系列求解器的传递是非常清晰的,SAMCEF Field提示用户定义与应用领域相关的数据,还可以发现不连贯的数据并提示用户更改。SAMCEF Field 的监视窗口允许用户跟踪计算的进展,如果发现问题就可以中断。它还可以显示出问题规模、需要的磁盘空间资源和估计计算需要的CPU时间等信息,一旦分析完成,就可以从导航器中非常容易地获得结果,除了标准图形输出(例如X-Y 图,等值图等),结果还可以插入到表格式分析报告中。SAMCEF Field 集成了报告生成系统,允许用户生成非常全面的超文本格式的分析结果文件(模型和分析任务总结、数据和特性参数、几何图片、网格图片等)。
LMS Samcef Field (64bit) rev 15-01 | 600.2 mb
The LMS Samtech Samcef Solver Suite is based on the finite element method (FEM) and covers a wide range of mechanical, thermal and thermo-mechanical applications – from basic to very advanced – primarily in the aerospace, defense and automotive industries.
You can apply the mechanical FEM solver solutions to linear applications such as linear static computations, modal and buckling analyses, linear dynamic simulations, super element generation, random excitations and shock responses. Nonlinear transient simulations can also be performed within this family of solutions. Material nonlinearities, geometric nonlinearities, contact conditions, large rotations and kinematic constraints can be taken into account. A dedicated module also exists for high-speed rotating machines. Thermal simulations allow solving transient analysis including convection, conduction, radiation and ablation.
Several levels of modelization are available including 2D plane stress or plane strain, harmonic and multi-harmonic, cyclic symmetry and full 3D.
As these modules are all part of the same family, you can switch from one analysis to another (convert a linear simulation to a transient nonlinear simulation), combine analyses (thermo-mechanical, pre-stressed modal analysis) or conduct co-simulations. With parallel computing capabilities, the LMS Samcef Solver Suite also allows you to solve very large finite element models.
About LMS
LMS is a leading provider of test and mechatronic simulation software and engineering services in the automotive, aerospace and other advanced manufacturing industries. As a business segment within Siemens PLM Software, LMS provides a unique portfolio of products and services for manufacturing companies to manage the complexities of tomorrow’s product development by incorporating model-based mechatronic simulation and advanced testing in the product development process. LMS tunes into mission-critical engineering attributes, ranging from system dynamics, structural integrity and sound quality to durability, safety and power consumption. With multi-domain and mechatronic simulation solutions, LMS addresses the complex engineering challenges associated with intelligent system design and model-based systems engineering. Thanks to its technology and more than 1250 dedicated people, LMS has become the partner of choice of more than 5000 manufacturing companies worldwide. LMS operates in more than 30 key locations around the world.
Name: LMS Samcef Field
Version: (64bit) rev 15-01
Interface: english
OS: Windows XP / Vista / Seven / 8
Size: 600.2 mb
Special Thanks team-SolidSQUAD
