CG数据库 >> CD-Adapco Star-CCM+ 8.02.011 (Windows/Linux)流体分析

CD-Adapco Star-CCM+ 8.02.011 (Windows/Linux)流体分析的图片1

STAR-CCM+是CD-adapco公司采用最先进的连续介质力学数值技术(computational continuum mechanics algorithms)开发的新一代CFD求解器。它搭载了CD-adapco独创的最新网格生成技术,可以完成复杂形状数据输入、表面准备——如包面(保持形状、简化几何、自动补洞、防止部件接触、检查泄露等功能)、表面网格重构、自动体网格生成(包括多面体网格、六面体核心网格、十二面体核心网格、四面体网格)等生成网格所需的一系列作业。

STAR-CCM+使用CD-adapco倡导的多面体网格,相比于原来的四面体网格,在保持相同计算精度的情况下,可以实现计算性能约3~10倍的提高。

STAR-CCM+ 软件是由CD-adapco Group公司开发的新一代通用计算流体力学(CFD)分析软件。

STAR-CCM+能很好地支持船的前期设计研究,目前在船类行业应用甚广。

STAR-CCM + is one of the most modern in comparison with competitors, a software suite designed to address problems of continuum mechanics. It is characterized by the extraordinary ease of use. STAR-CCM + includes the latest numerical algorithms such as advanced solvers raspredelennny (segregated solver) and connected (coupled solver), in addition, it is designed using the most advanced programming techniques. All this allows STAR-CCM + provide unprecedented accuracy, reliability and flexibility in solving problems in computational continuum mechanics.

Powerful new tools for building grids: from restoring the integrity of the surface (surface wrapping) before the creation of networks of polyhedral cells. The use of these new tools for building grids can reduce the clock while solving the problem.

Large set of physical models: laminar and turbulent flow of Newtonian and non-Newtonian fluids, multiphase flow, cavitation, radiation, combustion, development of boundary layer flows with high Mach numbers, the conjugate heat transfer, as well as new models for the calculation of heat exchangers and fans.

The use of arbitrary polyhedral cells: it requires less memory and speeds up the solution.

Powerful imaging: modeling and control parameters in the calculation.

Attaching, including the Russian interface.

Reliable results: based on sustainable, bezavostnogo solver STAR-CCM +.

Compatibility with existing models of software products: STAR-CD, ICEM, GridGen, Gambit.

Model, consisting of 1 billion or more cells: In contrast to all other CFD-packages, STAR-CCM + is specifically designed to implement scalable parallel computations on arbitrarily large grids.

Can solve relatively simple problems of strength (with the gas dynamics). pic

Date of Release: 2013

Version: 8.02.011

Developer: CD-Adapco

Website Developer: CD-Adapco

Bit depth: 32bit +64 bit

Compatibility with Vista: complete

Compatible with Windows 7: complete

Language: Multilingual

Medicine: Present (TeAM SOlidSQUAD-SSQ)

System requirements:

from personal experience - from junior i7, min 8 Gb RAM, nVidia, Bat Logitech.

CD-Adapco Star CCM + 8.02.011 (Windows/Linux) | 3.9GB
