ANSYS Maxwell 16 is the premier electromagnetic field simulation software for engineers tasked with designing and analyzing 3-D and 2-D electromagnetic and electromechanical devices such as motors, actuators, transformers, sensors and coils.

Maxwell uses the accurate finite element method to solve static, frequency-domain and time-varying electromagnetic and electric fields. A key benefit of ANSYS Maxwell is its automated solution process where you are only required to specify geometry, material properties and the desired output. From this point, Maxwell will automatically generate an appropriate, efficient and accurate mesh for solving the problem. This proven automatic adaptive meshing process removes complexity from the analysis process and allows you to benefit from a highly efficient, easy-to-use design flow.

ANSYS Maxwell 16 Release Highlights

- Integrated Solution for Electrical Machine

For the motor design segment, ANSYS RMxprt provides a full analytical solution for interior permanent magnet (IPM) topologies that are popular in hybrid and electric vehicles. ANSYS Maxwell includes improved meshing for the 2-D transient solver with a better and faster general-purpose mesher. TAU mesh technology is available in 2-D for motor cross sections; it provides a higher quality mesh with greater speed for complex models. It also provides auto-healing for dirty models. A novel pseudo-clone mesh creates identical mesh for symmetrical motor designs to increase accuracy and speed solution. Maxwell 3-D magnetic transient analysis is accelerated with HPC functionality using multicore, shared-memory simulation.

- Advanced Hysteresis Modeling

ANSYS Maxwell incorporates the most advanced material modeling in the low-frequency simulation space. Vector hysteresis modeling can analyze hard materials with large coercivity, suitable to analyze magnetization and demagnetization of permanent magnets. This capability is critical as it provides better accuracy in field computation in devices (machines, transformers).

A key feature in ANSYS Maxwell V16 is the ability to generate high-fidelity, reduced order models from the finite-element solution for use in ANSYS Simplorer, the multi-domain system simulation software from ANSYS. This capability creates a powerful electromagnetic-based design flow that enables you to combine complex circuits with accurate component models from Maxwell to design complete high-performance electromechanical, mechatronic and power electronic systems.

Bonus: Ansys Workbench Mechanical 14.5 LS-DYNA ACT Extension

ANSYS Workbench LS-DYNA is a new user environment for running ANSYS LS-DYNA within the ANSYS Workbench environment enabling users to set-up and run and post-process problems within a single Graphical User Interface. It is an extension to the ANSYS Mechanical GUI.

About ANSYS, Inc.

ANSYS brings clarity and insight to customers' most complex design challenges through fast, accurate and reliable engineering simulation. Our technology enables organizations -- no matter their industry -- to predict with confidence that their products will thrive in the real world. Customers trust our software to help ensure product integrity and drive business success through innovation. Founded in 1970, ANSYS employs more than 2,000 professionals, many of them expert in engineering fields such as finite element analysis, computational fluid dynamics, electronics and electromagnetics, and design optimization. Headquartered south of Pittsburgh, U.S.A., ANSYS has more than 60 strategic sales locations throughout the world with a network of channel partners in 40+ countries.

Name: ANSYS Maxwell

Version: (32bit) 16.0 (64bit)16.02

Interface: english

OS: Windows XP / Vista / Seven

Size: X32：734.3 mb X64： 877.6 mb
