Siemens NX 7.5-9.0 version 2014.12 Solvers Updates | 728 MB

Siemens PLM Software has released an updates of NXCAE_EXTRAS module to Siemens NX 7.5-9.0, is used to address thermal analysis requirements in a wide range of industries.

NX Thermal software provides heat transfer solutions and is an add-on module to either NX Advanced FEM or NX Advanced Simulation. NX Thermal can simulate conduction, convection and radiation phenomena for complex products and large assemblies. NX Thermal is used to address thermal analysis requirements in a wide range of industries including aerospace and defense, automotive and transportation, consumer products and appliances, energy, medical, electronics and semiconductors. In addition, NX Thermal can also be used with NX Flow, the NX-integrated CFD solution, for coupled thermo-fluid simulation.

NX Thermal continues Siemens’ long heritage in thermal simulation and leverages the same technology that underpinned the I-deas TMG solution. NX Thermal uses high-order finite volume-based technology on a FE mesh to accurately and efficiently simulate heat transfer phenomenon. It combines the versatility of FE-based analysis with the accuracy of a finite volume scheme. The NX Thermal solver technology allows simulation of NX parts and assemblies within complex thermal environments.

Included:

TMG 7.5.788 for nx-7.5 win32/64 (December 2014) (update only)

TMG 8.0.489 for nx-8.0 win32/64 (December 2014) (update only)

TMG 8.5.283 for nx-8.5 win32/64 (December 2014) (update only)

TMG 9.0.394 for nx-9.0 win64 (December 2014) (update only)

About Siemens Industry Automation Division

The Siemens Industry Automation Division (Nuremberg, Germany) supports the entire value chain of its industrial customers – from product design to production and services – with an unmatched combination of automation technology, industrial control technology, and industrial software. With its software solutions, the Division can shorten the time-to-market of new products by up to 50 percent. Industry Automation comprises five Business Units: Industrial Automation Systems, Control Components and Systems Engineering, Sensors and Communications, Siemens PLM Software, and Water Technologies.

HomePage: Here

Release Date: 2014

Version: 7.5-9.0

Developer: Siemens PLM Software

Bit depth: 32bit, 64bit

Language: Multilingual (Russian present)

Medicine: Cured (Team- SolidSQUAD)

System requirements: Preset NX 7.5-9.0 Win / Linux c module TMG Thermal / Flow Simulation (NXCAE_EXTRAS) and crowbar NX from SSQ

Note: It's only update module TMG Thermal / Flow Simulation (NXCAE_EXTRAS) for NX7.5-9.0 Win. To install, you must have pre-NX7.5-9.0 module TMG Thermal / Flow Simulation (NXCAE_EXTRAS) and crowbar from SSQ For more information, see. Readme.txt
