Duration 59m Project Files Included MP4

Making BIM Ready 3D Models from Point Clouds in Revit

Info:

With laser scanner point cloud data, engineers now have a way to visually assess a building site in 3D without even going there in person. It’s the perfect reference for viewing the state of the building site, and it’s also a great tool for checking if the project has been completed the way it was planned. But it really starts to shine when it gets converted into data-rich geometry in BIM tools like Revit. In this course, Making BIM Ready 3D Models from Point Clouds in Revit, you’ll master the workflow for converting 3D laser scanner point clouds into BIM ready 3D models in Revit. First, you’ll learn about setting up Revit for your scan to BIM conversion. Next you’ll learn to navigate through laser scan erroneous data and model basic building elements from point cloud data. Finally, you’ll learn about the best workflows for creating Revit families from laser scan data. By the end of this course, you’ll know how to convert most of the objects captured with 3D laser scanners into data rich Revit objects. Software required: Revit 2017. Software required: Revit 2017.

持续时间 59 米项目文件包括的 MP4

从点云在 Revit 制作 BIM 准备 3D 模型

信息︰

激光扫描点云数据，工程师现在有视觉评估 3D 在一个建筑工地甚至亲自去那里没有一种方法。它是用于查看的建筑工地，状态的完美引用，它也是一个伟大的工具进行检查，如果该项目已完成计划的方式。但它真的开始来照耀时它获取转换成数据丰富几何像 Revit BIM 工具中。在此过程中，使 BIM 准备好的 3D 模型，从点云在 Revit，你就能掌握三维激光扫描点云转换在 Revit BIM 准备 3D 模型的工作流。首先，您将了解 Revit 为您扫描到 BIM 的转换设置。下一步你要学会通过激光扫描错误数据导航和模型基本建筑元素从点云数据。最后，您将了解用于创建 Revit 家庭从激光扫描数据的最佳工作流。这门课程结束时，你就会知道如何转换大多数与三维激光扫描仪捕获到数据丰富的 Revit 对象的对象。所需软件︰ Revit 2017。所需软件︰ Revit 2017。
