Engineered Software, Inc.’s PIPE-FLO® Professional is the world’s leading fluid flow analysis and design modeling software tool. Within the PIPE-FLO® platform, users can experience a variety of modules that solve specific challenges.

These versatile tools provide value across multiple disciplines, industries and during all stages in the lifetime of a fluid piping system. They provide a common basis for operators, process and design engineers and management to understand, communicate and document their fluid piping systems and processes. Equally applicable to process, support and distribution systems in commercial, industrial and public facilities, PIPE-FLO® products are an invaluable tool for the design, commissioning, operation and modification of fluid piping systems.

PIPE-FLO® is designed to optimize and troubleshoot new or existing fluid piping systems. With a rich set of features and tools, PIPE-FLO® offers a variety of ways to view and analyze your fluid systems. Now you can reduce design time and avoid costly errors by eliminating the need for complex spreadsheets.

PIPE-FLO® v16.1 Key Highlights and Features:

Added a Flow Meter Sizing feature to calculate the diameter for balancing orifices and flow meters per ASME standards

Added a Pipeline Valve & Fitting K, Cv, Kv Calculator to estimate the performance of fittings from flow and pressure drop measurements

Performance optimization for faster editing and quicker solutions

Numerous UI improvements, including:

Added a Gradient Color Legend to the FLO-Sheet Report

Unit selectors to property grid for device design data fields

Automatically switch to the newly created Lineup

Default text orientation set to horizontal

Bug Fixes

PIPE-FLO® v16 Features:

Incorporated PIPE-FLO® Overtime 2009 functionality into PIPE-FLO® Professional enabling the user to simulate their system over a period of time

Added the ability to define Tank Geometries to the Tank devices

Centrifugal Pump Speed and Device Elevations can now be adjusted between lineups

New PIPE-FLO® Professional user interface with modern icon images

Over 6,000 NEW fluids

New fluid table feature

New PIPE-FLO® Overtime module fully integrates with PIPE-FLO® Professional v16*:

Create curves to represent specific operational trends for devices within the PIPE-FLO® Professional Model

Create a series of discrete events to depict program logic control

Graph the results of the simulation

Create multiple simulations within one PIPE-FLO® Professional Model

Live updates as the simulation is progressing in the PIPE-FLO® Professional Model

Playback simulation to focus on specific time slices within the simulation

Create printed reports of all the simulation parameters and results

Store the PIPE-FLO® Overtime file within the PIPE-FLO® Professional Model

Mix-and-match multiple simulations with multiple lineups in the PIPE-FLO® Professional Model

Define Tank Geometries to the Tank devices

Adjust Elevation between Lineups

Adjust Centrifugal Pump Speed between Lineups

Search for a specific device in a PIPE-FLO® Professional model

Model fan/blower devices through Centrifugal Pump(s) devices
