新版本5.x的 COMSOL Multiphysics

®

引入了多项新功能与产品，包括有望为仿真行业带来彻底变革的 App 开发器。

COMSOL Multiphysics

®

App 开发器可以通过 COMSOL 模型创建专业的 App 应用程序，提供给您机构中的所有工程和设计人员使用

极大地扩展了预定义的多物理场耦合

新的求解器算法可以对复杂 CAD 装配体实现快速网格剖分和仿真，并支持带有悬挂节点的非一致性网格

通过额外维度支持多尺度仿真

根据导入的网格创建几何，而后可以通过实体操作进行编辑

接口 & 多功能

通过新增的放样、圆角、倒角、中型面，以及加厚等功能，新增的设计模块扩展了现有的 CAD 操作工具箱

LiveLink

™

for

Revit

®

模块可帮助 COMSOL Multiphysics® 用户接入建筑信息模拟软件Autodesk® Revit®

可通过不同求解类型的组合进行多元分析优化

粒子追踪模块现已支持对粒子累积、侵蚀和刻蚀的仿真

电气

新增射线光学模块使用光线表述电磁波，可用于分析电磁波长远小于模型中最小几何尺寸的系统

由频率和材料控制的一键式网格剖分，可对无限元、完美匹配层（PML）以及周期性边界进行快速智能的网格剖分

等离子体模块新增了多个用于仿真平衡放电的接口

可通过半导体模块和波动光学模块进行光电元件仿真

力学

声学模块新增了两个用于模拟高频声波或几何声学的方法：射线声学和声扩散

传热模块新增模拟薄层、薄膜、杆和裂隙的功能，有效地减少对计算资源的需求

可通过结构力学相关模块模拟几何非线性梁、非线性弹性材料以及关节中的弹性

流体 & 化工

新增的代数湍流模型可以帮助实现更快的仿真：代数 y+ 和 L-VEL

支持栅板和风扇中的湍流分析

新增使用额外维度功能的反应颗粒床接口

新增化学接口，并对反应工程接口进行升级

Comsol Multiphysics 5.4 Update 4 | 4.1 Gb

The Comsol team has introduce an update 4 of latest release of COMSOL Multiphysics. The last version 5.4 includes two new products provides performance improvements and additional modeling tools.

Version 5.4.0.388 - Date: June 4, 2019

All COMSOL software products undergo stability improvements that are introduced as updates. The following list contains the most important improvements in COMSOL version 5.4 update 3.

COMSOL Multiphysics

- External materials no longer trigger multiple license key checkouts.

- Increased the robustness of COMSOL Client over WAN connections.

- Fixed a potential deadlock when connecting to a server using the COMSOL API or LiveLink for MATLAB.

- The page layout settings (such as page size, margins, orientation, and columns) of a specified custom Microsoft Word template file are now used when writing reports in Microsoft Word format.

- Fixed a bug that prevented writing a report from method code to a file specified in a file browser dialog box when using the default security settings.

- Fixed a problem where the MUMPS solver might crash or hang during cluster simulations.

COMSOL Server

- Fixed a layout issue with the COMSOL Server footer in Chrome 72+.

Composite Materials Module

- Fixed an issue in the Layered Shell interface, where the total thickness (lshell.d) would be erroneously computed if the layers on a certain boundary were not all selected in the same Linear Elastic Material node.

Heat Transfer Module

- Removed erroneous mesh suggestions generated by the Continuity feature for shells.

MEMS Module

- Corrected the equation display for the Heaviside step function.

Particle Tracing Module

- Fixed some inconsistency in the assignment of units for the Auxiliary Dependent Variable feature.

- The variable for "Total number of particles released by feature" now gives the correct solution in models that also have secondary particle emission.

- Two or more instances of Magnetophoretic Force are now allowed to be applied to different species in the same model.

Structural Mechanics Module

- Corrected an error occurring when the values of the total reaction force variables were wrong if a load was applied on a Rigid Connector in which the soft formulation had been selected.

- Corrected an error occurring when the Activation feature was combined with geometric nonlinearity in a 2D axisymmetric model.

Product:

Comsol Multiphysics

Version:

5.4 Update 4 (Build 388)

Supported Architectures:

x64

Language:

english

System Requirements:

PC / MacOsx / Linux

Supported Operating Systems:

*

Size:

4.1 Gb

* Review System Requirements:

Windows 10

Windows 10 Pro for Workstations

Windows 8.1

Windows 7 SP1

Windows Server 2016

Windows Server 2012 R2

Windows Server 2012

Windows Server 2008 R2 SP1

Windows HPC Server 2008 R2 SP1

__________________________________________

macOS 10.10, 10.11, 10.12, 10.13, and 10.14

___________________________________________

Debian 8 and 9

Red Hat Enterprise Linux 6.101 and 7.5

CentOS 7.5

Ubuntu LTS 14.04, 16.04, and 18.04

OpenSUSE Leap 15 and 42.3
