PICAXE微控制器芯片编程的快捷,简便,易于使用的图形流程图软件。适合中学和家庭用户.
Logicator for PICAXE----方便,快捷,简便,低成本的PICAXE芯片编程的图形化流程图为基础的软件.Logicator是一个图形化的流程图工具来生成PICAXE控制方案。在过去的20年里不断更新, 先后荣获多项行业奖项。最新版本提供了一个直观的工具和命令,快速生成可靠的PICAXE控制方案。
Logicator for PICAXE 3.6.7 | 43.5 MB
Logicator is a graphical flowcharting tool to generate PICAXE control programs. Constantly updated over the last 20 years, Logicator is one of the most common software applications found within UK school technology departments and has won a number of industry awards. The latest version provides a large range of intuitive tools and commands for quickly generating reliable PICAXE control programs.
Developing a Flowchart
Developing a flowchart is easy – simply pull out the desired flowchart cells from the toolbox, position them on screen and then connect them together with lines. Younger students find this graphical approach much simpler than typing textual BASIC programs and can learn to use the software within a few minutes.
To change a flowchart cell parameter, for instance the output pin number to switch on or off, simply double click on the cell and then use the drop down menus to select the appropriate pin. Comments can also be added to the flowchart if desired.
Parallel Task Processing
On all the new generation PICAXE M2 parts (08M2, 14M2, 18M2, 20M2) 4 parallel flowcharts can be processed at the same time. This simplifies students' programming of complex tasks. Logicator also fully supports sub-procedures and programming structures such as for…next loops.
On-screen Simulation
Once the flowchart is complete it can be fully simulated on screen. Simply click ‘Run’ and watch the cells highlight in turn as each command is processed. An on-screen virtual PICAXE chip shows the state of the input/output pins and can be used interactively to, for instance, change an input pin condition.
Project Board Simulation
Many of our low-cost take-home project kits are also directly simulated within the Logicator software. Simply open the project board simulation and try out your program on-screen without the need for any hardware. This feature gives great flexibility if limited school resources mean some students are learning about programming before they have finished assembled the kit.
In-Circuit Emulation and Testing
Sometimes it can be useful to test a feature, such as an analogue touch or light reading, on the real-life board instead of in simulation. Logicator allows the PICAXE M2 or X2 chip to communicate directly with the software, to, for instance report the light level falling on an LDR in real-time. This In Circuit Emulation allows the student to quickly identify the appropriate switching threshold values to use within their program.
Specialist Command Cells
Various specialist commands, for instance for LCD/OLED screens, infra-red sensors and ultrasonic range finders, allow students to very easily use the more advanced input / output devices within their projects. See the PICAXE Create system for more details of these supported input/output devices.
PICAXE Chip Programming
Logicator will automatically identify the AXE027 PICAXE USB download cable and use it to program your flowchart into the PICAXE chip. Logicator can be used with any PICAXE chip or project board.
