LayoutEditor布局编辑器是一款非常好用的软件编辑设计MEMS与集成电路制造平面设计软件，它包括DRC、宏，背景图像，提取，示意图，参数化细胞等功能。有限布局编辑，设计尺寸和尺寸不受限制，没有可用的文件格式的限制。它可用于复杂的设计，基本的编辑，简单的自定义设计，格式转换等，此软件功能强大，操作简单.

x86,x64 | Languages:English | File Size: 133/149 MB

Description:

The LayoutEditor is the most popular software to edit designs for MEMS and IC fabrication. It is also often be used for Multi-Chip-Modules (MCM), Chip-on-Board (COB), Low temperature co-fired ceramics (LTCC), Monolithic Microwave Integrated Circuits (MMIC), printed circuit boards (PCB), thick film technology, thin film technology or any other technology using photomasks. The LayoutEditor can freely be used to access our services like the supplier with photomasks.

User Interface:

The user interface of the LayoutEditor offers a outstanding usability as well as a high productivity. This is achieved by an extensive use of shortcuts and mouse buttons/keys combination together with clear visibility of this combinations. The most important handling functions like zooming and scrolling are integrated in each feature and need not to be called separately. Context menus are available for most parts of the user interface by a right mouse click.

A three button wheel mouse is recommended for a effective use, but it is also possible to use any feature with a touch pad or one button mouse. The user interface of the LayoutEditor is highly adjustable. The default appearance only includes most important parts. Further tool bars, sub windows can be added on demand via the main menu or via a right click in the empty area of the menu bar/tool bar. A availability of some tool bars/sub windows depend on the LayoutEditor version you use. Feature not available with the installed license key are not displayed. The parts of the user interface are described next. It will start with the most important part of the user interface, the main drawing:

Features:

-Editing

-Scripting

-File Formats

-SchematicEditor

-creating of new designs in all areas, (micro electronics, nano technology, MEMS, chemical sensors, PCB, ...

-automatic design editing with scripts,

-review and checks on finished designs,

-data preparation for mask production,

-design viewer,

-format convertions,

-integration platform for other design tools.

System Requirements:

OS:Windows vista / 7 SP1 / 10 x86-x64

layout_20190820_32bit.rar:

layout_20190820_64bit.rar:
