Cadence Allegro

系统互连平台能够跨集成电路、封装和PCB协同设计高性能互连。应用平台的协同设计方法，工程师可以迅速优化I/O缓冲器之间和跨集成电路、封装和PCB的系统互联。该方法能避免硬件返工并降低硬件成本和缩短设计周期。约束驱动的Allegro流程包括高级功能用于设计捕捉、信号完整性和物理实现。由于它还得到Cadence Encounter与Virtuoso平台的支持，Allegro协同设计方法使得高效的设计链协同成为现实。

Cadence OrCAD

产品以其直观的操作界面以及强大的功能而深受广大电子工程师们的喜爱。作为世界上使用最广泛的EDA软件，早在上个世纪八十年代起，OrCAD就开始为上百万的电子工程师个体以及企业团队提供全套的设计工具，它通过所有工具之间的无缝集成，以其前所未有的生产力为个人和企业带来了巨大的经济效益。 而OrCAD最新版本17.0很好的沿袭了这些传统。

x64 | File Size: 7.71 GB (Total)

Description:

OrCAD/Allegro one of the best and most professional software simulation and analysis electronic circuits and electronic design automation software division (Electronic Design Automation or abbreviated EDA) is.OrCAD consists of two words that in fact the state of Oregon was the birthplace of early versions of the software and CAD stands for Computer-aided design and computer design means is formed. Cadence SPB OrCAD OrCAD PCB set to Allegro PCB or also known, including various programs to design schematic, simulation and analysis of electronic is circuits.

Facilities and software features of Cadence SPB OrCAD:

-suitable graphical user environments and display circuit using icons

-OrCAD Capture and Capture CIS schematic design circuits in powerful environment

-Ability to design PCB (Printed Circuit Board stands and means the board or PCB)

-has an extensive library full of components and electronic devices

-Advanced simulation and analysis electronic circuits in a graphical environment PSpice

-environment Orcad PCB Designer / Editor to design and edit PCB

-Ability to interact with MATLAB and Simulink software

System Requirements:

OS:Windows 10 (64-bit) Professional, including Dark Theme mode; Windows Server 2012 (All Service Packs); Windows Server 2012 R2; Windows Server 2016.

CPU: Intel® Core™ i7 4.30 GHz or AMD Ryzen™ 7 4.30 GHz with at least 4 cores

Memory: 16 GB RAM

Space: 50 GB free disk space (SSD drive is recommended)

Display: 1920 x 1200 display resolution with true color (at least 32bit color)

GPU: A dedicated graphics card supporting OpenGL, minimum 2GB (with additional support for DX11 for 3D Canvas)

Monitors: Dual monitors (For physical design)

Supported MATLAB Version: R2019A-64Bit (For the PSpice-MATLAB interface)
