StormCAD CONNECT Edition Update 2.3 | 910.6 mb

The Bentley Hydraulics and Hydrology product team are pleased to announce the availability of StormCAD CONNECT Edition Update 2.3 (build 10.02.03.03). This release introduce improvements to help you be more successful.

CONNECT Edition Update 2.3 release of StormCAD (build 10.02.03.XX) - Date: Nov. 21 2019

Stability enhancements and fixes to reported issues

As with all new versions, this release includes fixes to various user-reported issues from the previous release, providing an overall more stable experience

StormCAD

is a comprehensive modeling software program for the design and analysis of storm sewer systems. StormCAD provides calculations for catchment runoff, inlet capacity, and gutters and pipe network flow.

StormCAD determines intercepted flow at network inlets, and routes bypass flow to selected bypass targets. Inlets can be computed using the U.S. Federal Highway Administration (FHWA) HEC-22 methodology and users can choose from grate, curb, slot, ditch, and combination inlet types. Engineers can use a variety of methods to compute headloss, including HEC-22 Energy and AASHTO. StormCAD uses the Rational Method to calculate peak flows in the storm sewer design, or accepts direct input of known flows for inlet inflows.

StormCAD allows users to specify Intensity-Duration-Frequency data using equations or tables. Modelers can then plot the IDF curves, and reuse their data for other projects in that region. Engineers can work with an unlimited number of sub-watershed areas and C coefficients for each inlet watershed. The constraint-based design features in StormCAD allow modelers to automatically design gravity piping and structures. The design is flexible enough to allow users to specify the elements to be designed, from a single pipe size to the entire system, by simply entering the appropriate design conditions: minimum/maximum velocities, covers, and slopes; pipe elevation offsets (including whether or not to allow drop structures), maximum spread and depth for inlets in sag; and minimum efficiency for inlets on grade.

This video covers a basic overview of the StormCAD, SewerGEMS and CivilStorm CONNECT Edition interface and tools.

Bentley Systems, Incorporated

is the global leader dedicated to providing architects, engineers, constructors, and owner-operators with comprehensive architecture and engineering software solutions for sustaining infrastructure. Founded in 1984, Bentley has nearly 3,000 colleagues in more than 45 countries, $500 million in annual revenues, and, since 2001, has invested more than $1 billion in research, development, and acquisitions.

Product:

Bentley StormCAD

Version:

CONNECT Edition Update 2.3 (version 10.02.03.03)

Supported Architectures:

x64

Language:

english

System Requirements:

PC *

Supported Operating Systems:

*

Size:

910.6 mb
