File Size: 272 MB

Description:

SOFiSTiK Bridge Modeler is a Revit plug-in for infrastructure projects like bridges. The main purpose is to create parametrized 3D bridge models using alignment parameters and generic families in Autodesk® Revit®. You can create a bridge axis using alignment parameters and define so-called placements (points of interest).

Bridge components are modelled along an axis between placements using parameterized bridge profiles. You can place the substructure element at the placement and connect it. Additional bridge equipment elements, such as parapets and railings, can be created as well. Automatic generation of cross sections, top view, longitudinal section representation and elevation points help in further detailing and documentation of the structure.

The model is fully parametric, which is useful for modeling complex structures and updating the entire model in case of modification.

SOFiSTiK Bridge Modeler tool supports a BIM concept, where 3D model is a data source for planning and construction.

Functionalities at a glance

-Creates 3D Bridge Axis using alignment information or imported data from external files (e.g. LandXML format)

-Creates bridge superstructure components using parametric profiles and axis geometry

-Creates multi girder bridge components according to given layout

-Creates bridge substructure components using generic families

-Creates bridge component array along an axis according to given layout

-Creates bridge equipment elements, like parapets and railings

-Fully parametric for axis, superstructures, substructures, parapets and railings.

-Automatic generation of section views with dimensions and top view with alignment information

-Automatic generation of longitudinal section representation with vertical alignment information

-Creates curved dimensions for axis and bridge edges

-Creates annotations of axis chainage

-Creates table with elevation points

-Alternatively creates a 3D solid model from a SOFiSTiK bridge project database

-Creates user defined tendons.

What’s new in SOFiSTiK Bridge Modeler 2020

-New workflow for multi girder bridges

-Creation of bridge component arrays along an axis

-Dimensioning tools for axis and curved edges

-Annotation elements for axis stations

-Family selection in dialogs supports Family Types

-Support of circular and unsymmetrical curves for vertical alignment

Interface

-After installation of SOFiSTiK Bridge Modeler an additional ribbon tab “SOFiSTiK Bridge” with the related tools and controls will appear.

-Holding the cursor over a tool on the ribbon a tooltip is displayed. The tooltip provides a brief description of the tool. While the tooltip is visible, you can press F1 to open the help that gives more information.

Workflow

-SOFiSTiK Bridge Modeler provides two workflows for creation of bridge geometry.

Axis-based Model:

-Create a bridge axis using horizontal and vertical alignment parameters.

-Define placements and their orientation along this axis.

-In case of variable cross sections, define variables along bridge axis.

-Create bridge superstructure along this axis using parametrized bridge cross section profile. Connect the axis variables to the bridge cross section profile.

-Create Substructure elements at placement’s position using adaptive families.

-Create Bridge equipment like parapets and railings along given edges.

-Modify your structure if needed.

-Create sections, top views and longitudinal section representation using tools from ‘Shop Drawings’ palette.

Compability:

Autodesk Revit 2020 (x64)

Whats New:

2020-2 Release (14.12.2019)

Resolved issues

-Fixed problem with missing elements and patterns in longitudinal section (secondary axis)

-Fixed problem with no material in components with two profiles

-Fixed problem with with edit tool for Cross Member Array

-Fixed problem with representation of placements that were defined with version 2020-0

-Fixed problem with import of axis range: location and direction

-Fixed problem with visibility of variable in Beams Dialog

-Fixed problem with incorrect dimensions while using shear mapping

-Fixed problem with parametrisation to axis of Cross Member Array

-Fixed problem with Shear Mapping by Girder Systems

Improvements

-Axis Constrained and Unconstrained functionalities were added

-Creation of straight axis between two placements two placements was added

-Superstructure Duplicate functionality was added

-Superstructure Repeater funtionality was added

-Matching Type Properties functionality was added in Superstructure creation tool

-Axis and Edge dimensioning can be created without Grid Elements

-Automatic variables with values of angles between placements and beam elements (in girder layout workflow)

-Available ‘Edit’ Icon in Modify Tab after selection of axis or bridge elements

-3D measure tool - in Other drop-down

-Edit Axis created by curve tool - in other drop-down
