geomcaliper是面向三维设计的创新性的几何厚度测量分析工具，由全球领先的cad\cam技术创新公司-geometric（几何）公司研发，geomcaliper突破了通用cad基于空间坐标的手工厚度测量分析技术，提供更加精准和高效的法线和滚球两种模型厚度测量分析方法，极大的提升设计阶段对模型的厚度测量、检查、分析的工作效率。

File size: 76 MB

3D Wall Thickness Checking and Analysis software – GeomCaliper for CATIA V5 and Creo Prametric. GeomCaliper is an innovative wall thickness analysis tool that facilitates measurement and checking of wall thickness on 3D models. GeomCaliper enables acceleration of the design review process for manufacturability. Unlike traditional measurement tools, GeomCaliper is fast and easy to use. Once you start using GeomCaliper, you’ll realize that checking thickness can be made really easy as well as quick.

The traditional methods of 3D wall thickness analysis are tedious and time consuming. Many time it provides erroneous results. GeomCaliper is simple, easy to use, fast, and accurate tool.

Salient Features:

Ray and Rolling ball available for checking wall thickness

Easy to locate critical thickness areas

Advanced visualization for easy interpretation of results

Ability to clip model at any section

Dynamic thickness display at point click

Compute thickness at selected region

Integrated with major CAD systems

Ability to ignore small thickness at edges

Create Customized reports in XML / HTML format

Benefits:

Quick and easy means of checking Design for manufacturing

Savings in downstream costs

Improved part quality, which is taken care at design stage

Improved design productivity and ease of use

Compatibility:

PTC Creo Parametric 3.0-6.0 Win64

Whats New:

Supported latest Creo Patches

CREO 3.0 – M190

CREO 4.0 – M110

CREO 5.0.5.0

CREO 6.0.3.0

Bug Fixed:

GeomCaliper floating license was only available for Admin user. Non-admin user was not able to fetch the license.
