Motor Design, a ANSYS business, announced the latest release of Motor-CAD 13.0.13.1 is unique software package dedicated to the electromechanical performance of motors and generators and the optimisation of their cooling.

ANSYS Motor-CAD

is a dedicated electric machine design tool for fast multiphysics simulation across the full torque-speed operating range. Motor-CAD enables design engineers to evaluate motor topologies and concepts across the full operating range, to produce designs that are optimized for performance, efficiency and size. Motor-CAD software’s four integrated modules—EMag, Therm, Lab, Mech—enable multiphysics calculations to be performed quickly and iteratively, so users can get from concept to final design in less time. Motor-CAD’s intuitive, template-based setup simplifies and automates the analysis process while its built-in electromagnetic, thermal and mechanical solvers offer valuable multiphysics insights into a motor design. The simulations can be completed in a matter of seconds thus allowing ample time and scope for extensive design space exploration. ANSYS Motor-CAD enables engineers to produce optimized electric motor and generator designs to help meet the size, weight, energy efficiency, cost and other specifications.

For deep analysis and validation of the motor design the Motor-CAD model can be transferred to ANSYS Maxwell, ANSYS Icepak and ANSYS Fluent. Combining these solvers with Motor-CAD delivers high-fidelity, 2D/3D analysis capability enabling users to analyze end-effects, demagnetization, core loss, hysteresis and other advanced electromagnetic phenomena, calculate the thermal envelope for operation and design complete motor cooling systems.

Interested in understanding more about multi-physics electric motor design and simulation using the Motor-CAD software tool? Watch our video tutorial.

Motor Design Ltd

is a strategic software partner to ANSYS Inc, a global leader in engineering simulation software. The software links between Motor-CAD and ANSYS, provide a seamless approach to modelling and analysing electric motor designs. The two technologies work well together, taking designs from concept to production through the complete product development life cycle.
