x64 | Languages:English | File Size: 3.32 GB

Description:

Sigrity 2019 software for simulation and signal integrity in high-frequency circuits. With the advancement of digital processing technology, the need for faster processing has grown increasingly, Prdzashgrhayy that necessarily needs to work faster circuits with higher processing speeds and higher frequencies are located. By increasing the speed signals for accurate speed up the signals on routes that are mounted on boards PCB or boards laminated issues and new problems arises in the case of Field, gripped engineers will be events such as interference, distortion and noise and signal integrity at high frequencies cause to be subject to threats.........

Sigrity OptimizePI™ technology:

-Upgraded signal integrity (SI) technology accelerates the time it takes to verify memory interfaces, serial links, and the plethora of other signals on a PCB that can cause a design to fail in the lab. The technology now features workflows and visions that can be used to quickly perform electrical rule checks that find impedance variations and excessive coupling. These checks require no models and can be run by both expert and non-experts in signal integrity........

System Requirements:

OS:Microsoft® Windows® 7 all versions (64-bit), Windows 10 (64-bit), Windows 2012 Server (All service packs), Windows 2016 Server (All service packs).

Note:Note: Clarity 3D Solver and Celsius with Hyper-V are not supported on Windows 7.

CPU:Intel® Core™ i7 4.30 GHz or AMD Ryzen™ 7 4.30 GHz with at least 4 cores

RAM:8 GB RAM / 64 GB RAM or higher

Space:50 GB free disk space / 500 GB free disk space SSD is recommended for primary operating system (OS) and simulation working directory

Internet:Microsoft® Internet Explorer® 9.0 or later

Display:1,024 x 768 display resolution with true color (16bit color) / Large monitor (or two) with Full HD resolution or higher

GPU:Dedicated graphics card with 1 GB video memory or higher........
