x64 | Languages:English | File Size: 1.44 GB

Description:

In Postprocessor, you can visualize the simulation results calculated in Solver. It is effective for product design reviews because in Postprocessor, you can check, for example, temperature distribution at the places that cannot be measured or observed in the actual products. You can output not only still images but also animations, as well as output files for CradleViewer.

Available import formats:

MSC Nastran, MSC Marc, images (BMP, PNG), 3D geometry (STL, Parasolid)

Available export formats:

Generic format for fluid data (.cgns), images (BMP, JPG, PNG), animation (AVI, WMV), 3D geometry (STL, VRLM, FBX)

System Requirements:

OS:Windows 8.1/Windows 10 (Verified by Version 1903)/Windows Server 2012/Windows Server 2012 R2/Windows Server 2016

CPU:64bit(AMD64/Intel64)

Memory:8GB or more depends on the number of element

Space:10GB for installation

GPU:Graphics card that supports OpenGL for Preprocessor/Postprocessor

Whats New:

Updates:official site does not provide any info about changes in this version.
