scFLOW is a next generation CFD tool that uses unstructured mesh to accurately represent complicated geometry. With Preprocessor that helps any level users generate high quality polyhedral mesh elements and construct complicated models, and Solver that ensures more stability and speed, scFLOW is capable of solving aerospace and automotive aerodynamics, performance of fans, pumps and other rotating equipment, design problems of electronic devices, multiphase phenomena, marine propeller cavitation, and varied problems. Through co-simulation and chained simulations coupled with MSC Software Marc, Nastran, Adams and Actran, more realistic coupling and multidisciplinary analyses with fluid, structure, acoustics, and multibody dynamics can be achieved.

Features and functions specific to scFLOW

Simplify preprocessor operations

The necessary operations with data from the CAD system for mesh analysis have been greatly simplified compared to previous versions. Saving information about the assembly and setting the details of the part give the impression of continuity in work between systems and reduce the load on the user.

Adaptive grid

Improved the function of local enlargement / grinding of elements during automatic meshing. An adaptive grid is generated from elements with the most suitable size for a particular geometry.

View mode

Data from the preprocessor can be displayed in viewing mode when the license is occupied by the postprocessor or by mesh generation.

Logging operations through the VB interface

Operations from the preprocessor can be saved as a log file using the Visual Basic interface. This makes it impossible to create custom scripts, but allows you to create an automated system in a short period based on the operations stored in the log.

Faster Stationary Analysis

The used optimization of the calculation algorithm increased the productivity of the convergence function and reduced the estimated cycle time for stationary calculations.

Calculation stabilization

For a grid of low quality elements, calculations can be automatically stabilized to prevent discrepancies.

Script development

Previously, complex settings (material properties or boundary conditions depending on time or coordinate) required the creation of C code and subsequent compilation. When using scripts, compilation is not required, and the functions themselves can be written in a preprocessor in JavaScript.

Moving Elements (Discrete Grid)

Performing calculations for moving objects: rotation of the fan, moving cars close to each other. The accuracy of the calculation of compounds of elements is improved by revising the algorithm. For the parallel solver, the memory efficiency has been improved, which should bring a significant effect in multi-core computing when working with large tasks.

Free surface

The software calculates the shape of the contact surface between gaseous and liquid substances. This function can be used in conjunction with functions such as moving borders, overlapping grids, and tracking elementary particles. In the case of stabilization of the phase surface, a stationary analysis is possible, which gives a result in a shorter time.

Details:

Cradle scFLOW 2020 Patch6 Win64

Release Year / Date:2020

Version:2020 Patch6 (May 2020)

Developer:Cradle Soft

Bit:64bit

Interface language:English

Tabletka:present

System Requirements:

OS:Windows 8.1/Windows 10 (Verified by Version 1903)/Windows Server 2012/Windows Server 2012 R2/Windows Server 2016

CPU:64bit(AMD64/Intel64)

Memory:8GB or more depends on the number of element

Space:10GB for installation

GPU:Graphics card that supports OpenGL for Preprocessor/Postprocessor

Whats New:

Updates:official site does not provide any info about changes in this version.
