ArtCAM

软件产品系列是一独特的CAD造型和 CNC CAM 加工解决方案，是复杂立体三维浮雕设计、珠宝设计和加工的首选 CAD/CAM 软件解决方案。可快速将二维构思转换成三维艺术产品。全中文用户界面使您能更加方便、快捷、灵活地进行三维浮雕设计和加工。广泛地用于雕刻产生、模具制造、珠宝生产、包装设计、纪念章和硬币制造以及标牌制作等领域。

Delcam ArtCAM

2011 Pro | 4.0 Gb

ArtCAM Pro is a unique software program that lets you produce high quality free-form 3D products from conceptual sketches or pictures faster than you ever thought possible. ArtCAM Pro also enables you to easily manufacture your 3D models. With ArtCAM Pro you can work directly from your sketches to build up a multilayered relief model, sculpt a 3D model on-screen or use customizable vector and relief libraries.

The advanced 3D modeling tools and flexible machining sdivategies in ArtCAM Pro provide the complete solution for all your CNC needs. ArtCAM Pro is a proven solution for many indusdivies including: Sign making, woodworking, 3D Engraving and Mold making, mold tool engraving, coinage, packaging...

The ArtCam line includes an entry-level version aimed at new CNC machining users, called ArtCam Express, for the design and manufacture of 3D and 2D items through woodworking, engraving and routing. According to

Delcam

, 'little or no machining knowledge' is required to use Express, as it features 'unique' software tools to guide the user through the process.

For more experienced users, there is ArtCam Insignia for production environments, which allows the creation of 'highly intricate' custom 2D or V-bit carved models from photographs or sketches, and ArtCam Pro for 3D models or 3D sculpted reliefs. There is also a version of ArtCam for jewellery makers.

Delcam explains the 2011 version of the software offers features such as increased working speed through a 64-bit format, a Contour Blend tool for complicated letters and shapes, and an option to open, reposition and resize a number of 3D reliefs within a model simultaneously without saving one particular arrangement. Layouts that are used regularly can also be saved using the system:

Using 64-bit software can increase the speed at which signmakers work as well as helping with larger, memory-intensive files.

To suit individual methods of working, ArtCAM gives users the freedom to customise and save their preferred interface layout. They also have the option to create their design in ArtCAM or import pre-created 2D or 3D artwork directly. Any 2D artwork can then be cut out for basic 2D signage or transformed into 3D shapes with ArtCAM’s unique modelling tools.

To help the design process, a sign can be made from several vector or relief layers, which can be shown or hidden, making them easy to manipulate. Layer information from imported files, such as PDF, DXF or AI files can also be preserved.

If required, designs on a particular relief layer can be split into layers and saved to the relief library. This adds to a library of over 400 free pieces of relief clipart that are supplied with ArtCAM. These can be opened, resized and repositioned as required prior to committing the reliefs to the design. These can then be embossed or sculpted from an array of design tools. Hand-carving effects or unique textures can also be added in a matter of minutes using ArtCAM’s texture toolpath strategy. New Bitmap to Vector outlining and Contour Blend tools make it even easier to accurately outline and create complex shapes.

Basic text can also be quickly generated with ArtCAM’s Text Tool, or if the designer prefers they can make their own unique fonts, which can then be stored and used at a later date for other signs.

Additionally, ArtCAM comes with an intuitive ‘Inlay Wizard’, which makes precise male and female parts with a perfectly flat surface for any inlaid sign. This will also ensure that all unsightly shadows are avoided when creating illuminated signs.

To help visualise the design, it can be rendered in numerous materials, including different types of wood such as mahogany or maple, complete with wood grain direction. If the sign requires outside approval, the design can be emailed as a rotatable 3D PDF.

Once authorised, the sign maker can then select the tools they want to use for machining from a database of over 250 routers and machine tools. To prevent material wastage, the software not only nests the pieces to be cut according to their true shape, but also calculates the previously defined machining strategies, cutting tools and machining parameters from imported DXF and PDF files. These can then be applied to all layers with the same name with a single click thanks to ArtCAM’s advanced ‘toolpath templates’.

Finally, a simulation can be run of the pieces being machined using the chosen tools and the given material block dimensions. This has proven extremely beneficial as customers can change the tools or machining strategies prior to machining, saving time and money.

About Delcam plc

Delcam is a world-leading developer and supplier of advanced CADCAM software, with more than 35,000 customers in over 80 countries. These clients vary from global names like Nike, Boeing and Mattel to small start-ups and individual craftsmen. Founded 30 years ago, we are the largest developer of product development software in the UK, with subsidiaries in Europe, America and Asia. Our global success has been recognised with many awards, including three Queen’s Awards for Enterprise in the last six years.

Name:

Delcam ArtCAM

Version:

2011 Pro build 215

Last Version:

2013

Home:

www.artcam.com

Interface:

multilanguage

OS:

Windows XP / Vista / Seven

Size:

4.0 Gb
