File size: 1.0 GB

SYSWELD is a 3D computer simulation system for welding and heat treatment processes.

Using the SYSWELD program, you can simulate the following heat treatment processes:

through hardening;

surface hardening;

quenching followed by annealing;

vacation;

austenite hardening

As well as chemical-thermal surface treatment:

cementation;

nitriding;

nitrocarburizing;

cyanidation.

SYSWELD simulates all the physical effects associated with heat treatment and welding.

Including:

electromagnetism (induction heating, etc.);

combined thermo - metallurgical analysis;

mechanical analysis;

diffusion.

Using the SYSWELD program, you can simulate a wide variety of welding technologies:

MIG

TIG;

spot welding;

laser beam welding and cutting;

electron beam welding;

electrode welding;

in a shielding gas environment, etc.

As a result of the calculation, you get information:

emerging stresses;

phase distribution in% (austenite, martensite, etc.);

temperature fields;

hardness distribution;

deformation.

System requirements:

To start with its own GUI, a pre-installed Exceed / Exceed 3D v14 (and higher) is required

Only solvers require a pre-installed ESI Visual Environment

Whats New:

Updates: official site does not provide any info about changes in this version.
