SPEOS是Ansys公司开发功能强大的专业用于光学设计、环境与视觉模拟系统、成像应用的光学仿真软件, 强大的解决方案提供完美的可视化光学系统，和直观的人机交互平台，其仿真技术已经广泛用于航空, 航天, 军工，汽车，轨道交通、通用照明等工业领域的研究机构和知名公司，是全球唯一整和机构进行光机系统的设计软件, 也是全球唯一可依据人眼视觉特征和材料真实光学属性进行的场景仿真的专业软件。Ansys SPEOS光学仿真软件基于可视化产品三维模型，直接采用数字化样机，使用虚拟环境仿真平台，进行视觉功效虚拟分析和人因环境评估，在产品设计阶段对的方案可行性进行验证，在设计前期发现、反馈和处理问题，使光学设计以高效率、超同步、易优化的工作实现最优的产品解决方案.

ANSYS SPEOS与SpaceClaim、CATIA、UG、CREO等主流CAD软件平台相结合，能够实现从结构设计到光学设计的无缝衔接，以OMS设备的准确光学属性测量结果作为软件的输入，基于材料的真实物理属性进行传感器及现实场景仿真，模拟结果可直接与实物照片进行对比。

SPEOS可以通过数字化建模为摄像头和激光雷达传感器提供测试环境，快速直观地将驾驶环境中摄像头和激光雷达的成像结果模拟出来。结合CAD平台，可以根据摄像头和激光雷达的三维造型、物理属性、约束条件，仿真传感器系统采集的数据，用于验证摄像头和激光雷达结构对成像的影响，探测器晶片对成像质量的影响，如CCD的光谱敏感性、动态范围、白平衡、像素大小与分布等对摄像头成像产生的影响，可以在早期设计阶段方便地评估不同设计方案在感知性能方面的区别。

x64 | File Size: 566 MB

Description:

ANSYS SPEOS for Creo Parametric- a comprehensive solution for calculating natural and artificial lighting in the design, optimization, visualization and validation of optical systems in a PTC Creo Parametric environment

ANSYS SPEOS is a software product based on OPTIS optical technologies for modeling and virtual prototyping of optical systems and components. It allows you to simulate the illumination and optical characteristics of the developed physical systems, reducing the time and financial costs of creating a prototype.

ANSYS SPEOS provides wide functionality for the design of lighting systems, optical sensors, indicators on the windshield (ILS), equipment for the far infrared region of the spectrum, autonomous driving systems and other electronic devices of the next generation, allowing you to simulate the behavior of products when changing lighting parameters, to conduct them validation and verification of compliance with industry norms and standards.

ANSYS SPEOS has lighting analysis tools in a wide range of radiation frequencies: from UV to near and far infrared, providing high-quality visualization based on the capabilities of human vision.

ANSYS SPEOS has an intuitive, user-friendly interface, and is fully compatible with the ANSYS Multiphysics ecosystem. Using HPC (High Performance Computing) technologies, SPEOS allows you to get results much faster and with greater accuracy. Access to ANSYS SpaceClaim Direct Modeler speeds up the development process. SPEOS Light Box exports the optical system with all its properties and dependencies to an encrypted file so that you can share your work with partners, while maintaining intellectual property in complete security. ANSYS SPEOS can be integrated with the main solvers of the ANSYS platform for experiment planning, model optimization and interdisciplinary analysis, for example, optical-mechanical or optical-thermal.

Key Features of ANSYS SPEOS

Extensive optical library

More than 4000 models of light sources (LEDs, fluorescent lamps, gas discharge lamps, incandescent lamps, etc.), materials for modeling the surface, texture or color, sensors, cameras and lenses, as well as SAE and ECE standards.

Infrared Analysis

Design of vision and detection systems (ground-based systems, unmanned aerial vehicles and satellites) operating in the visible region, near and far infrared regions of the spectrum (wavelength more than 2000 nm).

Changing production parameters

Analysis of the sensitivity of the product in terms of appearance, performance and functionality to changes in production parameters, such as shape or position, verification of compliance with regulatory requirements and analysis of tolerances.

Details:

ANSYS SPEOS 2020 R2 for CREO Parametric 3.0-6.0 Win64

Year/Release Date:2020

Version:2020 R2

Developer:Ansys Inc.

architecture:64bit

Interface language:English

Tabletka : Present (TeAM SolidSQUAD-SSQ)

System requirements:Preset

PTC Creo Patametric 3.0 Win64

PTC Creo Patametric 4.0

PTC Creo Patametric 5.0

PTC Creo Patametric 6.0

Whats New:

Updates: official site does not provide any info about changes in this version.

Screenshots
