3D Wall Thickness Checking and Analysis software – GeomCaliper for CATIA V5 and Creo Prametric. GeomCaliper is an innovative wall thickness analysis tool that facilitates measurement and checking of wall thickness on 3D models. GeomCaliper enables acceleration of the design review process for manufacturability. Unlike traditional measurement tools, GeomCaliper is fast and easy to use. Once you start using GeomCaliper, you’ll realize that checking thickness can be made really easy as well as quick.

The traditional methods of 3D wall thickness analysis are tedious and time consuming. Many time it provides erroneous results. GeomCaliper is simple, easy to use, fast, and accurate tool.

Salient Features:

Ray and Rolling ball available for checking wall thickness

Easy to locate critical thickness areas

Advanced visualization for easy interpretation of results

Ability to clip model at any section

Dynamic thickness display at point click

Compute thickness at selected region

Integrated with major CAD systems

Ability to ignore small thickness at edges

Create Customized reports in XML / HTML format

Benefits:

Quick and easy means of checking Design for manufacturing

Savings in downstream costs

Improved part quality, which is taken care at design stage

Improved design productivity and ease of use

This version supports CATIA V5R26-R30

Whats New:

Updates: official site does not provide any info about changes in this version.
