SIMPACK是机械/机电系统运动学/动力学仿真分析的多体动力学软件。利用SIMPACK软件,工程师可以像构筑CAD模型一样,快速建立机械系统和机电系统的的动力学模型,包含关节、约束、各种外力或相互作用力,并自动形成其动力学方程,然后利用各种求解方式,如时域积分,得到系统的动态特性,或频域分析,得到系统的固有模态及频率以及快速预测复杂机械系统整机的运动学/动力学性能和系统中各零部件所受载荷。

由于SIMPACK软件强大的运动学/动力学分析功能,可建立任意复杂机械或机电系统的虚拟样机模型,包括从简单的少数自由度系统到高度复杂的机械、机电系统(如链条、列车等)。对用户来说,SIMPACK软件可以被应用到产品设计、开发、优化的任何阶段。

力学方程求解有三项重要指标,分别为速度、精度和稳定性。由于采用了最新的数学力学方法,SIMPACK软件在计算速度极其优异的同时,仍保持了很高的计算精度和稳定性,这是其它同类产品所不具备的。由于求解器超常的能力,SIMPACK软件得到许多知名大公司的认同,其用户包括有BMW、DaimlerChrysler、Bombardier和Siemens等,且这些均为SIMPACK软件多年的忠实用户。

Intec

Simpack

9.6 | 1.8 Gb

SIMPACK is pleased to announce the official release of

SIMPACK 9.6

.

SIMPACK 9.6

is a major release delivering more than 180 new features and over 200 improvements.

Intec Simpack 9.6 Windows / Linux (x32/x64)的图片2

SIMPACK is a general purpose Multi-Body Simulation (MBS) software used for the dynamic analysis of any mechanical or mechatronic system. It enables engineers to generate and solve virtual 3D models in order to predict and visualize motion, coupling forces and stresses.

The most prominent changes of SIMPACK 9.6 include:

Solver:

- new Realtime Solver

- Improved Parallel Solver performance

- Linear algebra speed up

- Full integration history and statistics in result file SIMPACK

Pre:

- GUI scripting and macro recording

- Visualization of Marker Node assignments on flexible Bodies

- Message Log with traffic light error indicator and navigator

- Space Mouse support

SIMPACK Post:

- Mode shape animation with energy contouring

- Stacked Area and 100% Stacked Area plots

- Rainflow Filter

- Space Mouse support

Wizard:

- Flexible Body mode shape visualization

- Model and loadcase comparison

- Variant generation

- GUI scripting

- Space Mouse support

- Performance improvements

Elements:

- Gear Pair stiffness plots

- Extended Basic Gear Pair

- New KISSsoft based rolling bearing model

- New One-Way Clutch (Freewheel, etc.)

- Parallelization of IST Tower

- New Biomotion Car Driver

- Spline Coupling extension for helical splines

- New General Result Element

- Filters for Result Elements

Flexible Bodies:

- FAT4FEM based fatigue solution

- Acoustics analysis support (structure-borne noise)

- Principal stress computation

- Lumped mass matrix (gyroscopic forces based on unreduced FE-model)

- Utility for analyzing fbi and stress files

User Routines:

- Support added for Microsoft Visual Studio 2012 and 2013

- Support added for Intel Fortran Compiler 2013 SP1

General:

- Switch case and if/else if for formulas, Expressions and SubVars

- Performance improvements (Pre, Solver, Post)

Intec Simpack 9.6 Windows / Linux (x32/x64)的图片3

About SIMPACK AG

SIMPACK AG, a spin-off of the DLR (the German Aerospace Center), was founded in 1993 and now has representatives and partners all over the world. SIMPACK AG is solely responsible for the development of SIMPACK, a leading multi-body simulation (MBS) software. Apart from the distribution of SIMPACK, SIMPACK AG also offers consultancy, engineering and SIMPACK training courses.

Internationally renowned for accuracy, robustness, speed and versatility, SIMPACK is used primarily within the automotive, rail and wind energy sectors. SIMPACK is the market leader for simulating transient non-linear system behavior with flexible bodies, even up into the acoustic range. Diversity and good connectivity to various control, hydraulic and FE software enable SIMPACK to be easily integrated into any manufacturer's already-established development processes.

Name:

Intec Simpack

Version:

9.6 build 93

Home:

www.simpack.com

Interface:

english

OS:

Windows / Linux

Size:

1.8 Gb

Special Thanks TeAM SolidSQUAD-SSQ

发布日期: 2014-06-09
