Concise Beam是一个易于使用的工程软件，它基于Microsoft Windows平台，用于设计混凝土预制梁。

Concise Beam能够执行负荷的分析，并可按照最新版的ACI 318，CSA A23.3，AS3600标准对设计进行检查。

Concise Beam的关键代码参数可以模拟其它设计代码规范进行自定义。

桥梁设计可按照惯例进行强化，部分或是全部进行预张力处理(pretensioned)。程序可对任何的横截面形状进行建模，并且允许横截面可通过逐步式的(step-wise)成角度变换(prismatically)进行梁长度的改变。

当中的图形编辑器允许用户对任意横截面进行描述，描述内容可包括空隙率(voids)、开口(openings)，或是开孔(cut-outs)。

Concise Beam 4.59o | 14.1 Mb

Concise Beam is an easy to use program for the design of precast concrete beams. Concise Beam will perform a load analysis and design checks in accordance with the latest edition of ACI 318, CSA A23.3 & S6, AS3600, or NZ3101.1. Key code parameters can be customized to simulate other design codes. The beam can be conventionally reinforced, partially or fully pretensioned. It can model any cross-sectional shape and will allow the cross-section to vary prismatically (step-wise) over the length of the beam. A graphical editor allows the user to describe any cross-section, including voids.

Concise Beam currently works in two-dimensions using beam theory (b-region) but will also account for torsion along the beam. The user can work in metric or U.S. Customary (Imperial) units, with a variety of individual units (i.e. mm, cm, m), and switch back and forth at will. Libraries of industry standard cross-sections and materials are provided with Concise Beam. The standard libraries can be modified, extended and customized by the user.

Concise Beam Features

Beam Layouts

Simply supported beams

Cantilevers at one or both ends

Analyze any user defined cross-section

All standardized loads, load cases and combinations

Load distribution (including PCI hollow-core distribution)

Cast-in-place pour (topping or deck) definition with haunch

Reinforcement Options:

Reinforced precast concrete beams

Full or partially-prestressed (pre-tensioned) precast concrete beams

Deflected, cut & debonded tendons

Fully developed rebar and strand (dead anchor) ends available

Design Codes

American standard ACI 318-11

American standard ACI 318-08

American standard ACI 318-05

American standard ACI 318-02

American standard ACI 318-99

Canadian standard CSA A23.3-04

Canadian standard CSA A23.3-94

Canadian standard CAN/CSA S6-06

Australian standard AS 3600-2009

Australian standard AS 3600-2001

New Zealand standard NZ 3101.1:05

Customize each code, and work in metric or U.S. Customary (Imperial) units

Advanced Engineering Capability

Uses detailed methods whenever appropriate

Strain-compatibility section analysis

Lateral Stability Check of Tall Girders during Lifting and Transport

Shear Check of Hollow-Core with Filled Cores

Strand and Rebar slippage check

Cracked section analysis

Transfer, lifting, and final stress analysis

Shored construction option

Torsion analysis

Interface shear design check

Deflection and camber estimates

Maximum crack width estimate

Follows recognized methods as used in the PCI Design Handbook, CPCI Metric Design Manual, and the NPCAA Precast Concrete Handbook.

Productivity

Easy-to-read on-screen user's manual and context-sensitive help

Design tutorials and examples

Trial reinforcement design feature

Work in metric or U.S. Customary (Imperial) units (switch back and forth at any time)

Save most settings as defaults

Graphical cross-section editor

Results output in text reports and graphs

Comprehensive summary report of input and results

Full technical support

Regular program upgrades included with license

Exceptional responsiveness to user comments and suggestions

Computer Requirements

A computer capable of running Microsoft Windows XP or later

A video card compatible with Microsoft Windows OpenGL (recommended)

Supports any printer installed under Microsoft Windows

What's New in This Release:

Corrected a bug that was preventing the "Prestressed Force Induced in Rebar" report from being generated properly.
