产品材料的反复使用会导致疲劳。运用ANSYS

nCode

DesignLife软件进行工程模拟分析有助于产品设计人员避免失误，降低用户保修成本。

nCode DesignLife软件是一款领先的耐久性分析软件，由HBM提供并被全球OEM厂商和供应商广泛使用，其先进的疲劳分析功能与AWE融于一体。采用ANSYS疲劳耐久性分析软件，机械工程师在物理样机建立之前就能够解决复杂的产品使用寿命和耐久性问题。

失效的扳手

ANSYS协同仿真平台和疲劳耐久性分析技术的集成创建了一个简单易用的模拟环境，在一个标准的拖拽界面中将疲劳分析加入结构力学分析过程中。施加预定义的载荷时间序列（例如：在道路上实测的车辆数据），并通过ANSYS Mechanical软件的多次求解，获得有限元的响应结果。基于从实验中搜集的材料失效数据，可以预测模拟的循环载荷作用导致的疲劳失效。

ANSYS

14.5 nCode

DesignLife

| 1.5 Gb

ANSYS nCode DesignLife provides advanced fatigue analysis integrated within the ANSYS 14.5 Workbench environment. Results and materials data from simulations within Workbench can be directly accessed by DesignLife. This provides an unparalleled combination of ease of use and powerful fatigue analysis for ANSYS users.

Based on the nCode DesignLife product, the ANSYS advanced fatigue solution provides intuitive and easy to use tools for performing efficient large model analysis and complete usage schedules. You can access a wide range of fatigue analysis capabilities including stress-life, strain-life, multi-axial, weld analysis and a virtual shaker table.

The ANSYS nCode DesignLife family of products integrates advanced engineering simulation analysis and signal processing tools within a simple-to-use graphical workflow environment hosted inside the ANSYS Workbench platform. In addition to providing general stress-life and strain-life approaches, nCode DesignLife incorporates established methods for both spot and seam weld analysis. Vibration shaker tests can be directly simulated in the frequency domain. The product efficiently analyzes large finite element models and complete usage schedules. Fatigue material properties from the nCode DesignLife Material Library are available directly within the ANSYS Workbench environment, making fatigue analysis immediately accessible and providing a much larger material library to ANSYS Workbench users.

Computing fatigue estimates requires few additional steps once a stress analysis has been performed. Specific material data can be defined by the user or imported from the existing library of materials provided by our solutions. Load variations are defined before the fatigue computation and results are automatically imported from the stress analysis.

About ANSYS, Inc.

ANSYS brings clarity and insight to customers' most complex design challenges through fast, accurate and reliable engineering simulation. Our technology enables organizations -- no matter their industry -- to predict with confidence that their products will thrive in the real world. Customers trust our software to help ensure product integrity and drive business success through innovation. Founded in 1970, ANSYS employs more than 2,000 professionals, many of them expert in engineering fields such as finite element analysis, computational fluid dynamics, electronics and electromagnetics, and design optimization. Headquartered south of Pittsburgh, U.S.A., ANSYS has more than 60 strategic sales locations throughout the world with a network of channel partners in 40+ countries.

Name:

ANSYS 14.5 nCode DesignLife

Version:

8.0 ISR3 Build 125

Home:

www.ncode.com

Interface:

english

OS:

Windows XP / Vista / Seven

Size:

1.5 Gb
