ABViewer 是高品质、低成本、高效率的多功能设计及工程文档管理和图像浏览工具，是最专业的2D/3D CAD查看器，编辑器和转换器。支持30多种光栅和矢量图形格式，包括AutoCAD DWG, DXF, DWF, Hewlett-Packard HPGL, PLT, HGL, CGM, SVG, IGES/IGS, STEP/STP, STL, 3DS, TIFF, BMP, JPG, GIF等图像格式，并可以精确的调整图像或转换其它文件格式。程序具有批处理功能。

作为一个多用途的程序，ABViewer有着拖放图象，缩放图象和调整图象中心的功能，为他们的标识打印，转换和复制到剪切板，以便日后粘贴。 ABViewer可以轻松的管理文件。 ABViewer转换所有支持的文件为PDF， BMP， EMF， JPEG， GIF 和 TIFF格式。ABViewer现在有3个版本：企业版，专业版和标准版。

ABViewer Enterprise 10x/43 MB

ABViewer is a high-quality, cost-efficient multi-functional design and engineering document management application. ABViewer offers you a wide choice of professional viewing and editing tools. Support of more than 30 both raster and vector formats is provided, including AutoCAD DWG, DXF, DWF, Hewlett-Packard HPGL, PLT, HGL, CGM, SVG, IGES/IGS, STEP/STP, STL, 3DS, TIFF, BMP, JPG, GIF etc.

The 10th version includes the following features:

Convenient navigation in 3D mode while viewing 3D models

Supported formats: STEP, STP, IGES, IGS, BREP, STL, SAT (ACIS®)

Export into OBJ and STL

Copy with base point

Embedding of Xref files into the current drawing

Deleting of segments with one mouse click on the internal or external side of the selected outline

Quick access to CAD file settings, layers and layout options from the window Batch print

The window Structure now has search and access to files

Export of bit-mapped images into DWG and DXF in the window Batch

Command Convert to polyline converts the selected object into a polyline

Command Show performs zooming of the selected objects in the window of the program working area

Commands Explode all and Explode all inserts break connections between all compound objects in the drawing

The option Show contours of composite objects added and includes showing of the objects contours while relocating complex objects

Polyline editing improved and now parallel relocation of line segments is possible

The option Fillet for polyline that enables the user to create arc segments of a specified radius

The opportunity of filtration added in the window Layers

Command line improved, system variables added

Work in 3D mode has become easier due to convenient navigation. When object is pointed with the cursor its surface is highlighted.

Key features:

A combined viewer, editor and converter

Support of DWG, DXF, PLT, HPGL, TIFF, SVG, CGM, IGES/IGS*, STEP/STP*, STL*, 3DS* and other industry-standard formats (* for 3D formats please install a free 3D Plugin)

Printing of large formats (e.g. A1), on an A4 printer

The versatility to perform all operations from design to engineering with related documentation

An easy-to-use, fast, professional and powerful product

The most important aspects of ABViewer are quality, speed and price!

Supported formats:

AutoCAD DWG, DXF and all versions of DWF

Hewlett-Packard PLT Viewer: HPGL, HGL, HG, PRN, SPL

Scalable Vector Graphics: SVG

Computer Graphics Metafile: CGM

3DStudio (and many others): 3DS

Stereolithography file format (ANSI and binary): STL

Initial Graphics Exchange Specification: IGES1

Standard for the Exchange of Product model data: STEP1

PS Adobe

Windows metafile: EMF, WMF

All popular raster drawings supported, including TIFF, BMP, JPG, PSD, and GIF

Full list

Managing Portions of Drawings:

Copying portions of drawings to the clipboard in raster (BMP) and vector (EMF) formats

Printing portions of drawings

Saving portions as separate files (DXF, PDF, BMP, etc)

Editing Drawings:

ABViewer allows editing of both standard CAD formats such as DWG and DXF and other vector files: PLT, SVG, CGM. The application provides all the professional editor tools and enables operations supported by ‘heavy editors’, which are usually used for design work.

Conversion Features:

Copying to the clipboard as BMP, EMF/WMF

Exporting drawings to raster formats BMP, JPEG, GIF, TIFF with the possibility of additional settings

Saving vector data when exporting to the vector files: PDF, DXF, PLT, SVG, CGM, SWF, WMF, EMF

! Important: Clip Rectangle allows conversion of a selected part of the drawing

Batch Conversion and Batch Print

It is now much faster and easier to print or convert a large number of files into another format. ABViewer supports simultaneous conversion and print in batch mode – with the same settings for all files.

Quick Load and Scaling Big Black-and-White Raster Files:

In ABViewer we have applied our know-how concerning 1-bit (Black-and-white) raster formats management. Huge 15-20 thousand pixel files can be loaded in less than one second. They are immediately scaled – a feature that is very convenient with TIFF scanned drawings.

Measurement Tools:

Quick and easy setting of scale factor for measurements – no additional computations needed!

Changing of lengths, areas and perimeters

CAD File Management

You can hide all the texts and sizes just by one mouse click

Convenient switching between files

A large number of settings for snapping to objects, used for both editing and measurement purposes

Measuring distances on a drawing (including the scale factor setting)

3D viewing and editing

Viewing with six orthogonal projections and four isometric views

Automatic rotation of the loaded CAD file by a given angle

Managing layers

Color and black-and-white modes for CAD files

Choosing a background color

DWG/DXF/SVG/CGM arcs and circles can be drawn as smooth curves and saved as metafile arcs, and ellipses as EMF, which allows scaling without loss in quality

Setting the quantity of line segments when drawing circles, arcs, ellipses and splines

Merging drawings into one file

The possibility of viewing a CAD files structure

Supporting SHX-fonts, including UNICODE and BIGFONTS.

File Search

Favorites and Explorer panels give the possibility of fast file navigation. Thumbnails sub-programme allows viewing of all files in a catalogue before they are opened, including DXF, PLT and other files not managed by Windows or ordinary viewers. Due to the up-to-date tab-based document structure, you can navigate between files quickly and easily.

File Navigation

Dynamic scaling of the drawing with the help of the mouse-wheel, like in AutoCAD™. ‘Find text’ and ‘Find point’ lead to the necessary part of the drawing quickly. If only the contour of a detail is required in the drawing, it is possible to hide all the texts and sizes by one mouse-click; it is not necessary to open layers and change their visibility.

Redline

The Redline mode or commentaries to the drawing provide additional information that is ‘applied over’ the drawing but does not change the basic file. All editing elements are at your disposal in this mode. Commentaries and remarks, together with the basic file, can be printed or converted to another format. A drawing can be supplied with many commentaries of this kind. In addition, the path to the redline files containing the remarks can be saved, which allows to load the files automatically when the drawing is opened next time.

Print

The print feature provides the user with a vast range of capabilities. Both a single file and a set of files can be printed with predefined settings. The ‘Print preview’ dialog box contains a large number of settings, for example DWG/DXF line width, color and layers, and nil width value. Printing ‘in tiles’ allows printing images on any number of sheets of any size with the necessary scale. For example, large images (A0, A1 etc) can be divided into many small pages of a different size for subsequent pasting together into one big drawing. Any ‘tile’ can be printed separately. Therefore, if one page seems defective (e.g., because of problems with the printer), it is possible to re-print this page separately. As an alternative to printing the whole file, it is possible to print a selected area (with the help of ‘Clip Rectangle’ that selects the required part) and print the view area. Color drawings can be printed with a black-and-white printer in high quality and without grey halftones. There is a number of frames that can be inserted onto the printed page.

Preset sizes for standard formats (ISO-A; DIN: A4, A3, A2, A1, A0; US: A, B, C, D, E).

Supported Formats

ABViewer can be associated with all the supported formats

Supported CAD formats:

AutoCAD™:

DWG – all versions (from 2.5 to 2012 inclusive)

DXF ASCII (all versions)

Template files: DWT

Autodesk Design Web Format: DWF

Hewlett-Packard HPGL: PLT, HGL, HG, HPG, PLO, HP, HP1, HP2, HPGL, HPGL2, GL2, PRN, SPL

Scalable vector graphics: SVG

Computer graphics metafile: CGM

Adobe Acrobat Document: PDF

Encapsulated PostScript File: EPS

Adobe Postscript: PS

Supported raster pictures:

Bitmaps: BMP, RLE, DIB

Icons: ICO

Compuserve GIF: GIF

Arts & Letters thumbnail: GED Images

Autodesk: CEL, PIC Images

CALS Raster: CAL

Images Dr. Halo: CUT, PAL

Images GFI fax: FAX

JPEG images: JPG, JPEG

Images Kodak Photo-CD: PCD

Images Paintshop Pro: PSP

Images Photoshop: PSD, PDD

Images Portable network graphic: PNG

Images Portable pixel/gray map: PPM, PGM, PBM

Images SGI: BW, RGB, RGBA, SGI

Images SGI Wavefront: RLA, RPF

Images TIFF: TIF, TIFF

Images Truevision: TGA, VST, VDA, WIN

Images ZSoft Paintbrush: PCX

Supported vector images:

Metafiles: WMF

Enhanced Meta File: EMF

Supported 3D file formats (built in 3D Viewers)

AutoCAD™ drawing file format: DWG

Drawing Exchange Format: DXF

3DStudio (and many others): 3DS

Stereolithography file format (ANSI and binary): STL (STL Viewer)

Initial Graphics Exchange Specification: IGES/IGS1 (IGES Viewer)

Standard for the Exchange of Product model data: STEP/STP1 (STEP Viewer)

WaveFront and many others: OBJ

GNU Triangulated Surface: GTS

Triangular Irregular Network vector file format: TIN

ASCI Scene Export: ASE

Blitz 3D model files: B3D

Ghoul2 (GLM) model files: GLM, GLX, GLA

Pulsar Studio LMTS File Format: LMTS

Lightwave3D object file (6.0 or above): LWO

Nurbs surfaces vector file: NURBS

NormalMapper files: NMF

FSRad OCT files: OCT

Stanford Triangle Format vector file: PLY

Virtual Reality Modeling Language vector file: VRML

MDC files: MDC

Quake2: MD2

Quake3: MD3

Doom3 mesh vector file format: MD5

Half-Life: SMD

Quake3: BSP

Export to the following formats:

Adobe Acrobat Document (*.pdf)

Adobe Flash (*.swf)

AutoCAD™ DXF (R2000): (*.dxf)

Bitmap Files: (*.bmp)

Computer Graphics Metafile: (*.cgm)

GIF (*.gif)

Hewlett-Packard HPGL: (*.plt)

JPEG: (*.jpg)

TIFF (*.tiff)

Scalable Vector Graphics: (*.svg)

Windows Metafiles: (*.wmf)

Windows Enhanced Metafiles: (*.emf)

Languages

There is support for more than 30 languages:

Arabic，

Brazilian Portuguese，

Bulgarian，

Belarusian，

Chinese

，

Croatian，

Czech，

Danish，

Dutch，

English，

Estonian

，Finnish，

French，

Greek，

German，

Hebrew，

Hungarian

，Italian，

Japanese，

Korean，

Norwegian，

Polish，

Portuguese (Portugal)，

Romanian，

Russian，

Serbian，

Slovak，

Slovenian，

Spanish，

Swedish，

Taiwanese，

Turkish，

Ukrainian

Home Page

-

http://www.cadsofttools.com/en/products/abviewer.html

ABViewer Enterprise 10.0.0.25

Download iiiup

http://www.iiiup.com/4jj/ABViewer.10.0.0.25.rar
