HMI编程软件

创新

> 视频浏览和音频记录

> 实时显示连接到Magelis XBT GT/GK 和 GTW 或 iPC的照相机上的照片

> 在Magelis XBT GT/GK 和 GTW 上对视频文件进行MPEG格式编码/解码,或在Magelis iPC上进行AVI f格式转换

> 同时进行视频流播放和记录

> 在Magelis iPC上播放第三方MPEG视频流

简化您的维护操作

> Web Gate 远程访问功能 : 使用IE浏览器通过以太网管理您的HMI应用程序

> 用户界面友好的数据管理功能

质保期 : 18个月

优势

你就是“导演”

一个软件系列覆盖您所有的HMI应用设计需求 : Vijeo Designer Lite 用于小型显示终端,Vijeo Designer用于图形终端和工业PC

得益于她的友好界面使得画面组态变得更加简单,并且她提供了丰富的高级功能,如多媒体功能和远程访问功能,提高了操作效率

应用

简单的和复杂的设备（汽车、电子元器件、制药、化工等）

第三产业和基础建设 : 食品&饮料,水处理等

Schneider Electric Vijeo Designer v6.1.4.352 SP4 | 4.2GB

The cross-platform Vijeo Designer configuration software can be used to create operator dialogue applications for controlling automation systems.

Vijeo Designer and a suitable terminal can be combined to provide a solution for each and every control station requirement, at the cost of a simple software reconfiguration.

Capable of supporting video image streaming, the Magelis Vijeo Designer offer provides access to new types of application. Users can view their process instantly or following a delay, on the same screen as the HMI dialogue.

Vijeo Designer uses Magelis Ethernet TCP/IP connectivity and is therefore able to support WEB Gate remote access, the sharing of application data between terminals, the transfer of recipes and logs for variables and much more-all with total security.

Vijeo Designer is the HMI component of SoMachine. Vijeo Designer will run on any PC with Windows XP Professional or Windows 7. It supports WYSIWYG simulation of the expanded application (without Magelis GT/GK/GTW/GTO terminal or target Magelis iPC), the simulation of PLC variables (I/O, internal bits and words) and ensures that the application runs in total security on the Magelis GT/GK/GTW/GTO base terminal or Magelis industrial PCs.

Dedicated to Magelis HMI configuration, Vijeo Designer software is a standout performer.

Innovations

Remote access to your HMI thanks to the apps Vijeo Design’Air and Vijeo Design’Air Plus : * Vijeo Design’Air enables you to Connect to your HMI remotely for an interactive mirror view of your application

* Vijeo Design’Air Plus, enable you to get a fully operable view of your application from wherever you are

Video view and record function

View your images in real time from a camera connected to Magelis XBT GT/GK and GTW or iPC

Encoding/ decoding of your sequences with recording on demand in MPEG format on your Magelis XBT GT/GK and GTW, or in AVI format on your Magelis iPC.

Simultaneous viewing of recorded and real time sequences

Display of the third party MPEG format streaming on Magelis iPC

Simplify your maintenance operations

Web Gate remote access function: handle your HMI applications via a simple internet navigator using architecture Ethernet.

User-friendly data exchange thanks to the Data Manager function

Self download from FTP server to transfer a new project

Intelligent Data Service add-on

Full and safe processes, compliant with the traceability requirements of the FDA 21 CFR part 11 norm thanks to dynamic dashboards or report printing: traceability of the key values of the process and of the operator’s actions, IDV secured file format

Benefits

One single software for an entire range!

A software range to cover your Magelis HMI application design needs : Vijeo Designer Lite for Magelis XBTN and XBTR, and Vijeo Designer for Small Panels, Advanced Panels and iPC.

Thanks to their user-friendly interface, it also offers functions such as multimedia capabilities and remote access for more efficiency.

Applications

Simple or complex machine builders (automotive, electronic components, pharmaceutic products, chemical).

Tertiary industry and infrastructure: building, food and beverage, water and waste treatment.

Supported types of panels

Magelis Compact iPC

Magelis Smart

Magelis XBT GK

Magelis XBT GT

Magelis XBT GTW

Magelis STO & STU

Magelis XBT GH

Magelis iPC

Magelis HMI GTO

Communication protocols

Fipio / Fipway

MELSEC

Modbus Plus

Profibus DP

Sysmacway

Uni-Telway

USB

Modbus RTU master

Modbus TCP master

Modbus 32-bit extensions

ELAU PacDrive

UniTE TCP / IP

Simatic

Allen-Bradley

Ethernet / IP Explicit

Toyopuc PC3J

ROC Plus

Updates: official site does not provide any info about changes in this version

Version: v6.1.4.352 SP4

Developer: Schneider Electric

Purpose: Industrial Software

Bit depth: 32bit, 64bit

Language: Multilingual

Medicine: Present

1）安装，运行install.exe文件

2）在参考号码 - VJDSNDTGSV61M

3）在序列号 - VJDSNDTGSV6

4）等待安装并关闭该程序。

5）补丁程序，请转到该文件夹_Patch
