Altera最新版设计软件Quartus II软件v14.0引入了最新开发的快速重新编译特性，这一使用方便的设计流程进一步缩短了编译时间。此外，

Quartus

II软件v14.0还包括了下一代设计空间管理器(DSE)——使用方便的一款设计优化工具，以及增强了Qsy，Altera的系统集成工具。该版本也实现了Cyclone

®

V SoC和Arria V SoC的最终时序模型。

Altera的最新版本设计软件——Quartus

®

II软件Arria

®

10版v14.0，为业界提供最先进的设计环境，支持您马上开始20 nm Arria 10 FPGA和SoC设计。使用这一全面的设计套装，您会体验到编译时间比竞争产品平均快2.5倍，设计性能高出一个速率等级。Quartus II软件Arria 10版v14.0是目前20 nm唯一可马上进行设计而且最全面的设计软件。

采用Quartus II软件Arria 10版v14.0，您可以使用最终引脚输出和时序模型完成您的电路板布局，达到时序收敛。电路板设计人员现在可以在工程样片上使用最终引脚输出，在系统原型设计上使用早期功耗估算器模型。马上下载Quartus II软件Arria 10版v14.0，开始您的设计!

IP Core支持

Quartus II软件Arria 10版v14.0对20 nm最佳的知识产权(IP)内核提供了全面补充以加速设计周期。Altera还针对Arria 10 FPGA和SoC，优化了其同类最佳的IP内核，包括100G Ethernet、300G Interlaken / Interlaken Look-Aside，以及PCI Express

®

Gen3 IP内核。在Altera的Arria 10 FPGA和SoC中实现时，这些同类最佳的IP内核实现了FPGA业界最佳的性能。如果要了解详细信息，请访问

Quartus II软件Arria 10版v14.0新增IP特性

页面。

SoC支持

Quartus II软件Arria 10版v14.0具有全部新的硬核处理器系统(HPS) Qsys MegaWizard的特性，使得设计人员能够配置Arria 10 SoC HPS中的处理器和外设。电路板设计人员通过最终引脚列表以及利用Arria 10 FPGA和SoC器件之间完整的引脚兼容性可以开始对

Arria 10 SoC

进行原型PCB设计。软件应用于开发人员可以利用28 nm Cyclone V和Arria V SoC以及20 nm Arria 10 SoC之间的代码兼容性的优势。他们可以将28 nm SoC中广泛的应用代码、工具、操作系统支持，以及开发套件重新用于加速软件开发和原型设计。

Arria 10 FPGA和SoC简介

在20 nm，Altera的Arria 10 FPGA和SoC是性能最好的，性能比竞争器件高出一个速率等级。Arria 10 FPGA和SoC的功耗比前一代FPGA和SoC低40%，具有业界唯一的硬核浮点数字信号处理(DSP)模块。如果需要了解详细信息，请访问

Arria 10 FPGA和SoC

网页。

Altera

Quartus

是Altera公司推出的一种可编程逻辑器件电子设计自动化开发软件。它可以识别电路的Verilog或VHDL高级硬件描述语言表述，或读取指定格式的线路图；进而完成逻辑仿真、功能验证、逻辑综合等任务，对器件的进行编程，即将设计项目转换到实际的硬件。该软件提供了逻辑电路的可视化设计以及向量波形的仿真等功能。

Altera Quartus II version 14.0 with Additional Components | 20.1 Gb

Altera Corporation released its Quartus II software version 14.0, the FPGA industry’s #1 software in performance and productivity. Altera maintains its software leadership position for FPGA and SoC designs with this latest release by delivering 2X faster compile times on average over the closest competitor’s design tool suite.

Quartus II software version 14.0 allows users to be more productive and achieve the fastest FPGA and SoC design closure in the industry. The latest release includes a rapid recompile feature that reduces compile times by up to 4X when making small design changes and a best-in-class PCI Express (PCIe) IP solution that delivers enterprise-class performance. In addition, this release offers expanded AXI support in the Qsys system integration tool and a rapid prototyping design flow in the Altera SDK for OpenCL.

A re-architected rapid recompile feature allows users to make small changes to their design and recompile in a fraction of the time versus doing a full compile. Using rapid recompile, designers will experience a speed up of up to 3X for pre-synthesis HDL changes and up to 4X for post-fit SignalTap II logic analyzer modifications, while preserving placement and routing for the unchanged portion of the design. Rapid recompile now supports all 28 nm Cyclone V, Arria V and Stratix V FPGAs.

Altera continues to bolster its best-in-class IP portfolio with the FPGA industry’s highest performance PCIe solution. Altera’s best-in-class PCIe solution boosts application performance by delivering up to 6.7 GB/s throughput and greater than 400K input/output operations per second (IOPS). The solution includes a newly architected DMA engine, enterprise-ready device drivers and reference designs that greatly simplify the evaluation and design integration process.

Enhancements to the Qsys system integration tool simplify the process of connecting system-level hardware components. Qsys expands its support for the AMBA AXI3 and AXI4 specification to include support for AXI4-Lite, a light-weight version of AXI4, and AXI4-Stream, for point to point connections. These enhancements enable better design reuse by supporting a broader range of custom IP and easing integration with Altera and third-party developed IP.

More info:

http://www.altera.com/whats-new

About Altera

Altera programmable solutions enable designers of electronic systems to rapidly and cost effectively innovate, differentiate and win in their markets. Altera offers FPGAs, SoCs, CPLDs, ASICs and complementary technologies, such as power management, to provide high-value solutions to customers worldwide.

Name:

Altera Quartus II

Version:

(64bit) 14.0.0.200 with Additional Components

Home:

www.altera.com

Interface:

english

OS:

Windows / Linux

Size:

20.1 Gb
