GGCam 2.1 Professional | 45 MB

Do not loose any more time to program your CNC manually. With GGCam, go from your CAD model to the final part in few mouse clicks.

A strong CAM engine

The CAM engine is based on post-processors written in python script language. It is an open system that allows you to write your own post-processors. The tool integration in the GGCad interface provides the user with the possibility to define profiles, contours, pocketing, drilling in just some mouse clicks. The tool path can be visualized in 3 dimensions. Macro and python CAM script can be added to customize features. A GCode editor with syntax highlighting offers a simple and fast visualization of the output file.

Drilling

Select, create, modify one ore more drilling as you would do it with a pen on a sheet of paper. Drilling, peck drilling, taping, boring.

Tabs

Add tabs automatically. Tabs allows to leave the part fixed to the raw material. This is useful to avoid thin parts to be sucked up or broken. Define the number, width, length.

Plasma/Oxy, entry points

When a plasma starts, there are burrs created which have to be avoided. To do so, define offseted start points. GGCad will add automatically the tool path to enter beside the final tool path. This can be an arc tangent to the tool path (plasma/oxy) or a strait line (laser/EDM).

Machining

Different machining operation are available. Pocketing, zigzag, inside/outside offset, drillings, circles, spirals.

Text

Engrave your text with the support of TrueType and Autocad fonts.

3D Chamfer/Fillet

The 2D interface supply a tool to create chamfer or fillet corner on the edges of the part, in one mouse click.

3D Interface

GGCad support 3D file formats such as STL, 3DS, Collada. It can now work on 3D shapes. Tools such as zigzag, offset, profile allows to create tool path in 3D. It gives the possibility to do engraving, moulding.

Bitmap support, heightmap

Bitmap file like bmp, jpg, png can be imported to generate height map.

Projection

Project text or any other polyline onto a 3D surface. The projection will follow the curves.

Simulation

A complete simulator reproduces the machined part by material removing.

Python Interface

The python script interface has new features to create your own 3D shapes.

Macro

Macros can be integrated during tool path generation. Some are predefined like tool radius or tool length compensation. Macros can be written in ISO code or in python.
