ADA 3D Mesh2Surface For Rhinoceros 5  (x64) | 2 MB

Boost Rhinoceros software and make reverse engineering quick and easy. Mesh2Surface is a plug-in for Rhinoceros providing tools to convert your meshed scan data to complete CAD model in minutes rather than hours.

Features

Mesh2Surface is a plug-in for Rhinoceros version 4.0 and 5.0. The plugin is 32 Bit and 64 bits working on Windows XP and Windows 7.

With a number of simple but efficient features to optimise the process of converting scanned data to a perfect CAD model. See some of the functions in action by clicking on the video links.

The video demonstration will show how the tools can optimise the process of creating a CAD model from digitised physical objects.

- Fit basic primitives like planes, cylinders, spheres, cones

- Revolved and extruded surfaces

- Advanced editing of profile for revolved and extruded surfaces

- Segment meshes based on fillet areas

- Measure the fillet radius

- Constraint extracted shapes

- Find the symmetry of the object

- Align an object to the world coordinate system

- Build best fit free form surface from part of the mesh

- Create curve based free form surface

- Keep all the surfaces in the Rhino file and modify them any time.

Home Page

-

http://www.mesh2surface.com/
