Surfacing with SOLIDWORKS

Video: AVC (.mp4) 1280x720 15&30fps | Audio: AAC 48KHz 2ch | 275MB

1h 24m | Intermediate | Apr 21, 2015

Get up to speed with the surfacing tools within SOLIDWORKS. Gabriel Corbett will teach you the key tools to be proficient with the surfacing package. First, learn how to create basic extruded, revolved, ruled, and offset surfaces. Then dive deeper into modifying surfaces with the Extend Surface, Cut Surface, and Knit Surface tools. Along the way, Gabriel introduces real-world examples that show how surfacing can improve your designs and allow you to create shapes that would otherwise be impossible to build. The course wraps up with some tips for fixing common problems with fillets and solids and manipulating faces.

Topics include:

*Defining planes for surface creation

*Creating splines and 3D curves

*Making revolved surfaces

*Building boundary and lofted surfaces

*Offsetting a surface

*Trimming and untrimming surfaces

*Adding fillets

*Fixing corners

*Deleting, moving, and replacing faces
