功能强大的专业热分析软件。主要面向航天航空和汽车及交通运输行业座舱系统的空调系统的热舒适性分析。基于隐式有限元求解方法分析求解，能够解决各种热分析问题。新的GUI，具有数据导航树可以清晰的对整个项目进行管理。

软件特点

编辑

领先的热舒适性分析软件：汽车热舒适性分析，假人模型和人体热舒适度评价。

集成了：

THESEUS-FE传输系统，

材料类型以及群输入输出功能，

脚本语言扩展，

一维单元类型，

空气/真空菜单图层，

不同版本间的质量传递系统功能，

对流库，

备份等。

Theseus-FE 5.0.1 | 406.6 mb

P+Z Engineering is proud to announce the launch of THESEUS-FE version 5.0, a offers an implicit Finite Element (FE) steady-state or transient solver for a wide range of heat transfer problems. With this release the new E-Coating module becomes available to the general public.

The user is capable of applying different types of thermal boundary conditions such as: convection, radiation, contact, inner/outer heat sources, etc, and all multi-boundary conditions can be time or temperature dependent and also applied element wise by reading from files.

The high performance radiation solver allows for short-wave radiation with transmission and refraction in elements, and also long-wave radiation with diffusive and multiple reflection. The necessary view-factors are calculated with the most modern algorithms from computer graphics and take into account aspects of shading. To allow for the computation of larger models, adjacent elements can be grouped together as 'patches' which serves to reduce the calculation time and disc space.

Together with the THESEUS-FE features 'Ventilation' and 'Airzones', ventilation systems and air flow regions can be simulated, where by convective coupling of adjacent elements is implicitly solved for. FIALA-FE, an integrated manikin has been developed based on the latest research results in the area of thermo-physiology for the simulation of human thermal responses and thermal comfort predictions. Life-like simulations can be performed taking into account such aspects as blood flow, breathing, evaporation, metabolic responses, sweating, shiver, cardiac output and a complete energy balance between the manikin and its environment.

The thermal manikin FIALA-FE is fully integrated in our solver THESEUS-FE. It is a powerful tool providing thermal comfort indices globally and locally, which then can be used for optimization. The manikin in a vehicle for example can be fully coupled with the surrounding ambiance, whereby convection, radiation and contact with the seat as well as evaporation, breathing and humidity are accounted for simultaneously. The insulation resulting from clothing can be uniquely assigned to each body part.

The THESEUS-FE GUI (graphical user interface) offers the user the capability to read in NASTRAN-format finite element meshes and prescribe all the necessary physical parameters. To minimize the set up time, a material data bank for easy selection is readily accessible through the GUI. For the clothing of the manikin, typical summer and winter ensembles are also available.

All results are condensed to a single output file (public HDF format). With the integrated THESEUS-FE post processor, the results can be viewed, exchanged and printed as curves or contour plots. The results from THESEUS-FE can also be exported or mapped to various formats, and with other commercial or free-ware post processing tools visualized.

The major features of this release are:

- parallelization of large parts of the numerical solver including the equation system solver, view factor calculation and ray-tracing for solar loads

- brand-new module to simulate the electrophoretic deposition process of a body-in-withe in a paint path

- new opimization methods für more efficient and robust optimization and calibration of model parameters and sensitivity analysis

- modelling of optical refraction which can for example be used to model automotive headlights with their complex lens systems

- new vast material database with plenty of values for thermal properties of materials and surface properties for radiation

- dozens of enhancements in the GUI for more convenient pre- and post-processing

About P+Z Engineering GmbH

P+Z Engineering GmbH provides development services. The company develops parts and components for customers. Its services include design, CAE and simulation, test and validation, electrics and electronics, and project and quality management. It serves industries, such as automotive, aerospace, special and commercial vehicles, machine building and plant manufacturing, and medical engineering. The company was founded in 1967 and is based in Munich, Germany with additional offices in Ingolstadt, Stuttgart, Cologne, Bremen, Wolfsburg, and Augsburg, Germany; and Cluj-Napoca, Romania. P+Z Engineering GmbH operates as a subsidiary of PCL Group GmbH.

Name:

Theseus-FE

Version:

(64bit) 5.1.08

Home:

http://www.theseus-fe.com

Interface:

english

OS:

Windows / Linux

Size:

396.4 mb
