StruSoft FEM-Design Suite是一款先进的建模软件，主要用于承重混凝土、钢材、木材结构（按照欧洲设计规范）的有限元分析和设计。独特的用户友好的工作环境是基于熟悉的CAD工具（使模型创建和结构编辑变的简单与直观）。

FEM-Design快速和容易的特点，使得它对于所有的建设任务类型（从单一的元素设计到大型结构的全局稳定性分析）来说都是非常理想的，并使其成为结构工程师的最佳实践工具。

StruSoft FEM-Design Suite v14.00.004的主要特征有：

使用直观的CAD工具或从BIM软件直接导入，使得结构模型在3D环境下都可以很容易的被创建；

有限元网格自动生成和优化；

自动设计功能有助于选择最有效的横截面或钢筋布置；

抽壳单元的合成和连接力可以进行很容易的评估；

结果会以三维图形、轮廓线、调色板或剖面等的形式被显示；

自动更新的项目报告可以从内置的FEM-Design文档编辑中被创建。

StruSoft FEM-Design Suite 14.0 | 680.9 mb

StruSoft AB, a development software company with more than 30 years of experience in specialized software applications for the entire building industry, introduces FEM-Design version 14.0, is an advanced modeling software for finite element analysis and design of load-bearing concrete, steel and timber structures according to Eurocode.

The unique user-friendly working environment is based on the familiar CAD tools what makes the model creation and structure editing simple and intuitive. The quick and easy nature of FEM-Design makes it ideal for all types of construction tasks from single element design to global stability analysis of large structures and makes it the best practical tool for structural engineers.

Here is a list of the most important features and changes that have been introduced in FEM-Design 14:

- FD 14 is now a full 64-bit software so all memory of the computer can be utilized.

- The list dialog improved in several ways (elements shown in the list can now be filtered, the list can now be send to documentation and Excel file).

- In RC design the User has the possibility to place single layer surface reinforcement.

- A new object, the Fictitious shell is added to the Structure tab.

- Detailed result for line support group reaction and connection forces are now available.

- In FD 14 local stability results can be displayed. After calculating the load combinations the Local stability results (Overturning of walls and Sliding) are available in Display results dialog.

- In Material settings dialog different creep coefficients can be specified for Serviceability Limit State (SLS) and Ultimate Limit State (ULS). It has some consequences in load case calculation and results.

- In Load groups dialog the User has the opportunity to choose one of the combination methods offered by Eurocode 0. Two methods of determining the combination of actions are allowed for the STR Ultimate Limit States.

- The calculation of the load combinations can be run with different options. They can be set in Calculations dialog by selecting the Load combination items and clicking on Setup by load combinations. The User has the opportunity to choose: Non-linear calculation (NL), Cracked-section analysis (CS), Second order analysis (2ND), Imperfection calculation (IS) for each Load combinations.

- The graphical performance is increased and more development is expected in future versions. In FD 14 the DirectX graphic engine is faster than OpenGL on most of the computers.

- User interface is improved.

About StruSoft AB

StruSoft AB has been a leading engineering software provider for the building industry for more than 30 years. StruSoft has achieved this by innovative and visionary development, working in close co-operation with leading construction companies, engineering firms, consulting companies and precast factories around the world.

StruSoft's main software packages FEM-Design, WIN-Statik, PRE-Stress, IMPACT and VIP-Energy have been applied in analysis and design, 3D-modeling, detailing, assembly and energy. The software applications have been developed into well proven products, and are now used by customers in more than 20 countries around the world. The customers experience increased efficiency and productivity, time saving and increased quality when engineering buildings with StruSoft’s software applications.

Name:

StruSoft FEM-Design

Version:

Suite 14.00.004

Home:

http://www.strusoft.com

Interface:

english

OS:

Windows 7even / 8

Size:

680.9 mb
