Cadence Design Systems, Inc., a leader in global electronic design innovation, has released the hotfix of Cadence Allegro and OrCAD 17.0 design solution with new features, enhanced customization capabilities, and simulation performance improvements that provide customers a shorter, more predictable path to product creation.

DATE: 08-07-2015 HOTFIX VERSION: 005

===================================================================================================================================

CCRID PRODUCT PRODUCTLEVEL2 TITLE

===================================================================================================================================

1260002 ALLEGRO_EDITOR INTERACTIV Symbols with ALT_SYMBOLS_HARD property are mirrored by Edit - Move - Mirror

1356381 ALLEGRO_EDITOR INTERFACE_DESIGN PCB Editor hangs when adding net to a net group

1357843 ALLEGRO_EDITOR PLACEMENT The net association of a via changes when a replicated circuit is placed using Place Replicate

1394052 ALLEGRO_EDITOR INTERACTIV Edit Mirror preview is wrong

1412635 APD DATABASE APD crashes on saving design

1427732 SIG_INTEGRITY SIGNOISE Constraint Manager does not display results of Xtalk simulation

1436070 SIG_EXPLORER SIMULATION Incorrect rise time for IBIS buffer when simulated in SigXplorer

1438848 APD OTHER Layers of a module, mirrored using the Mirror Geometry command, change on refreshing the module

1440332 ALLEGRO_EDITOR ARTWORK The oblong slot hole changes size in the IPC2581 output

1441672 SIP_LAYOUT ASSY_RULE_CHECK ADRC Hangs and does not close

1443249 MODEL_INTEGRIT GUI Model Integrity does not show version number in QIR 9

1444932 ALLEGRO_EDITOR INTERFACES When exported to PDF, the octagonal pads in a padstack are larger than their size in Allegro PCB Editor

1446259 ALLEGRO_EDITOR INTERFACES Export PDF prints a big square box instead of a frectangle on the board

1450135 ASI_SI OTHER Linked differential signal waveform of SigNoise report is not displayed in SystemSI viewer

Intall:

Installing Hotfix SPB17.00 analogous Hotfix SPB16.60.

It happens that after the upgrade, new problems. In any case, for the rollback, backup directory SPB_16.60 \ tools.

Do not make the top Hotfix patched SPB, will not operate.

Example:

It was the directory d: \ CAD \ SPB_16.60 \ installed the patched version.

Rename the d: \ CAD \ SPB_16.60 \ in d: \ CAD \ SPB_16.60 = \

Create an empty d: \ CAD \ SPB_16.60 \

Copy d: \ CAD \ SPB_16.60 = \ compnts.dat in d: \ CAD \ SPB_16.60 \

Make a Hotfix.

Make a patch of SPB_16.60.000 (enough to make the d: \ CAD \ SPB_16.6 \ tools, the rest in the Hotfix has not been updated)

Transfer content for the d: \ CAD \ SPB_16.60 \ in d: \ CAD \ SPB_16.60 = \ with replacement

Rename the d: \ CAD \ SPB_16.60 = \ in d: \ CAD \ SPB_16.60

Version: SPB17.00 b005
