行业标准的 CAD 软件工具和功能

体验功能强大且价格低廉的 CAD 软件，将二维设计转换为三维实景。CorelCAD™ 2016 提供可在交互式工作区使用的可自定义的二维制图工具和卓越的三维设计工具，以在所有工业类型中实现您的 CAD 目标。借助本地 .DWG 文件格式支持，实现与同事和业务伙伴的 CAD 文件无忧协作，以提高您的工作流程效率。拥有与 Ribbon UI 类似的工作环境，三维打印功能和 STL 文件输出。由于同时针对 Windows、Mac OS 和 Android 平板进行了优化，CorelCAD 可以在您选择的平台上提供卓越的速度、性能和自定义功能。

直观

探索全新增强型二维绘图和三维建模工具，为任何计算机辅助设计项目带来完美准确度。快速输入、注释缩放、平视显示等快速响应性工具所带来的设计优势，使功能进一步增强，以保持高精确度。

强大

通过复杂的 CAD 引擎（由 ARES 提供技术支持）与屡获殊荣的 CorelDRAW 技术的强强联合，将关键图形与工作流程相整合，带来高水平的 CAD 性能体验。提高任何 CAD 项目的效率，并借助额外的 CorelCAD 插件扩大 CAD 优势。

用途广泛

使用 Windows Ribbon 或经典的 UI 工作区传达您的日常 CAD 设计要求，以取得图形优势。凭借为您的需求量身定制的高水平制图和设计工具，让您每次都能收获丰富的视觉效果和骄人的成绩。

价格低廉

获得符合您的 CAD 设计要求及公司预算的行业标准工具。使用全新的 CorelCAD Mobile，在您选择的平台上（Windows、Mac 或 Android）轻松设计。以大部分 CAD 软件选项的一小部分成本，获得一个完整的解决方案，满足您的一切所需。

CorelCAD 2016 build 16.x Multilingual | MacOSX | 178 MB

Discover the powerful and affordable CAD software that transforms 2D designs into 3D reality. CorelCAD™ 2016 provides customizable 2D drafting tools and superior 3D design tools within an interactive workspace to achieve your CAD goals in all types of industries. Increase your workflow productivity with native .DWG file format support for worry-free collaboration on CAD files with colleagues and business partners. Work in a familiar environment with the ribbon UI, 3D print-ready features and STL file output. Optimized for Windows, Mac OS and Android tablets, CorelCAD delivers impressive speed, performance and customization on the platform of your choice.

Intuitive

Explore new and enhanced 2D drafting and 3D modeling tools that seamlessly bring precision to any computer-aided design project. Gain added design strength from responsive tools like Quick Input, Annotative Scaling, Head-up display and more to maintain pinpoint accuracy.

Powerful

Experience high-level CAD performance with the strong combination of a sophisticated CAD engine, powered by ARES, and the award-winning CorelDRAW technology to incorporate key graphics into your workflow. Bring efficiency to any CAD project, plus expand your CAD strength with additional CorelCAD plugins.

Versatile

Communicate your day-to-day CAD design needs using Windows Ribbon or classic UI workspaces to achieve graphic superiority. With high-caliber drafting and design tools that are customizable to your needs, you’ll have visually rich and impressive results every time.

Affordable

Get industry-standard tools that match your CAD design needs and your company’s budget. Design with ease on the platform of your choice, Windows, Mac, or Android with the new CorelCAD Mobile. Find everything you need in one complete solution for a fraction of the cost of most CAD software options.

NEW

Quick Input

Establish a command interface in your project using the cursor in the drawing area. It’s an efficient and time-saving feature that brings commands directly to the cursor so when you move it, the tooltips track and enable input of coordinate positions, lengths, angles, lines and more – when and where you need it.

Drawing Tabs

Stay organized in CorelCAD on Windows with the ability to instantly switch between several documents that are open and active at the same time. Use the DrawingTabs command to show drawing tabs at the top of your drawing window. It’s an efficient feature that allows you to open, edit, close and save multiple drawing windows.

Layer States Manager

Keep the layers in perfect order by using the new Layer States dialog. Save in a LayerState to manage the appearance of design components with named layer states, turn them on and off, and switch between displays. It will save, restore and manage configurations of layer properties and states, and can be shared across projects.

Multiline BlockAttributes

Edit and format many different types of multiline BlockAttributes with the pop-up toolbar. You can specify maximum width of text lines, insert attribute fields and revise annotations.

CorelCAD Mobile

Design and annotate on the go with CorelCAD Mobile, the latest Android tablet version of CorelCAD that complements the existing PC and Mac platforms. Get all the speed, performance and customization you need for any size CAD project on the platform you want.

Annotative Scaling

Keep your important text readable and separate from your drawing and viewport scale functions. As you move around within your design workspace, you now have the ability to view legible text at all times including printouts regardless of how small or large your design elements become.

Head-up Display

Use the Head-up toolbar to select various entities and then zoom in on the selected entities to make required changes. With the ability to edit your entities in one place, you can set the line style and line width, change layers, create dimension entities or make a Block.

Dimension Offset Distances

Use this time-saving tool to align the dimension lines with consistent distances from surrounding shapes. With the dimension location snap, you can place dimension lines at specified distances from measured linear shapes and between successive dimension lines, saving time and effort to achieve perfectly aligned technical drawings.

System Requirements:

Mac OS X v10.7 (Lion) or higher (incl. v10.11 (El Capitan)
