管道套件(PipelineSuite)之一的管道工作室（PipelineStudio）模型，可以通过先进的仿真技术，改善天然气和液体管道的离线计划和设计仿真的效率及精确度。通过一些例如稳态和瞬态水压分析的技术，管道工作室（PipelineStudio）始终提供高质量的商业决策方案，用以实现更佳的财政业绩。一旦管道工作室（PipelineStudio）为您的管网创立了一个离线工程模型，在客户应用软件中会嵌入一个相同的模型，从而增强特殊的商业运作程序以及全面的资金性能。

灵活度

管道工作室（PipelineStudio）所具备的灵活度足以把您的管网当作一个整体考虑。PipelineStudio甚至可以同GIS及其它公共数据库和应用软件—包括其他ESI公司的产品相互整合起来。

管道工作室适用于：

1、计划编制，设备战略策划 ;

2、分析水压的特征  ；

3、设计管道及设备；

4、用于预测目的的模型；

5、来自现存数据的仿真情况。

管道工作室(PipelineStudio)可以帮助操作员在不进入控制室的情况下观察操作程序改变时所产生的反应。通过研究已制定的操作行为的模拟结果，给出高质量的决策方案，从而减少维护费用，降低维护风险。

PipelineStudio(管道工作室)开放的基础结构和普通的设计构造，使其易于同PipelineStudio(管道工作室)系列的其它产品配合使用。作为附加功能，PipelineDataExchange(管道数据交换)可以轻松地同GIS、CIS、SCADA以及其它公共数据库相互整合起来。

ESI PipelineStudio 4.0 | 216.4 mb

Energy Solutions International, Inc. (ESI), a leading supplier of software solutions to worldwide oil and gas pipeline companies, has released 4.0 version of PipelineStudio - the industry-leading solution for pipeline design, simulation and analysis.

PipelineStudio combines the most robust and proven simulation engines with a user friendly yet powerful set of features to offer a truly complete pipeline engineering tool on your desktop. Whether you are working with gas or liquid pipelines, PipelineStudio offers powerful, easy-to-use and flexible capabilities for pipeline design, engineering, planning and modeling.

New in PipelineStudio Release 4.0:

- TNet engine for Liquid

The TNet engine now incorporates Liquid network modelling. Both the TGNET and the TLNET engines are now retired.

- Parametric Study Manager

PipelineStudio now supports parametric studies through a new parametric study tool.

- User Defined Logic

The long awaited User Defined Logic is now available. This features enables complex simulation control using Python or PowerShell scripts.

- Survey Grooming

PipelineStudio now supports survey grooming within the survey dialog.

- Review unused configuration elements

Elements that are not being used can be identified and removed from the configuration.

- Sensor nodes on compressors and regulators in gas simulations

Sensor nodes are now available to control parameters remote from the device.

- Units management and decimal point display in network view

Number of decimal places displayed may be controlled in the units manager.

- Batch quality tracking available for gas simulations

Adds another options for quality alongside the random choice method.

Other significant changes include:

Wall temperature display updated.

New ramps available.

DRA updates included in 4.0.

Simulation changes to LPG and NGL modeling and how pump status is ramped.

About Energy Solutions International Inc.

Energy Solutions International, Inc. (ESI) is a leading global supplier of enterprise software solutions for oil and gas pipeline companies. Customers deploy ESI solutions to increase revenues and improve the performance, efficiency and safety of their operations. Founded in 1976 and headquartered in Houston, Texas, ESI serves more than 250 clients in 45 countries through its offices in the United States, United Kingdom, United Arab Emirates, India, Singapore, China and Canada.

Name:

ESI PipelineStudio

Version:

4.0.0.0

Home:

http://www.energy-solutions.com

Interface:

english

OS:

Windows XP / Vista / 7even / 8 / 8.1

Size:

216.4 mb
