CPFD Arena Flow 7.5.0 | 179.8 mb

Arena-flow, LLC has release 7.5 version of CPFD Arena Flow, is a revolutionary package for core-making and tooling design; it’s based on the science of two phase computational fluid dynamics, (CPFD) enabling technology that makes the modeling of core blowing possible.

Arena-flow is the only foundry engineering software package which uses the revolutionary CPFD technology to model sand core filling and curing. CPFD simulates not only the granular sand motion and air flow in the tooling, but also the significant interaction between the two.

Consistent core quality is a prerequisite for achieving controllable casting quality. Low-density cores result in core breakage or unacceptable metal penetration. High density cores lead to shake-out difficulty or gas-related casting defects. Uniform, consistent, controllable core quality is desired.

Arena-flow gives you the information needed to accurately and efficiently solve foundry problems.

Significant improvements from Arena-flow 7.5 include the following:

- New core fill-time map feature to quickly highlight potential low-density or high-scrap regions;

- New grid generator interface with import-grid, non-linear gridding and improved core/grid viewing capabilities;

- Support for 64-bit Windows 7 operating system;

- Side-by-side installation available with prior Arena-flow releases.

About Arena-flow, LLC

Headquartered in New Mexico, USA - the birthplace of computational modeling - Arena-flow, LLC is recognized as a global technology pioneer after successfully commercializing its unique Arena-flow Sand Core Engineering Software based on the CPFD technology. Today, Arena-flow is in used at OEMs and foundries world-wide.

Why is it called CPFD? Invented at the Los Alamos Scientific Laboratory in the 1950's and 60's, computational fluid dynamics, called "CFD", is a mathematical expression of the physics of the movements of fluids, that is liquids and gases. CFD computer software simulates real-world fluid-flow events, such as modeling the flow of air over an aircraft wing, or predicting the flow of an oil spill in a river channel. Sand in an hour glass is said to "flow", and so for many years CFD computer codes were used to model and predict the movement of particles as well as fluids.

Name:

CPFD Arena Flow

Version:

(64bit) 7.5.0

Home:

http://www.arena-flow.com

Interface:

multilanguage

OS:

Windows XP / Vista / 7even / 8 / 8.1

Size:

179.8 mb
