VERICUT软件可以模拟CNC加工,用来检测错误、潜在的碰撞以及低效的加工区域。

在把程序传入机床之前,VERICUT可以让数控编程人员发现并纠正错误,这样可以避免工件的试切。

VERICUT也可以优化数控程序的切削速度,获得更高的加工效率——甚至在高速铣削上!Vericut 7.0亦重新设计了刀具管理器,使Vericut的程式优化模组——OptiPath变得更容易使用。

刀具优化库将设置在刀具管理器 ,这样不仅简化了使用过程,而且不同的刀具可以参考同一个优化库。

新的刀具装配向导允许用户在一个简单的用户介面里,通过对话方块的形式创建一把新铣刀。

如果用户已经在其他刀具库 建立了一把刀,用户可以参考或复制整个刀具,或刀片、刀柄,建立新的刀具。

Vericut模型输出功能在7.0里得到了加强,能够输出CATIA V5、ACIS SAT和STEP模型,模型输出能够在Vericut类比NC程式的任何过程中创建CAD模型。

这个模型包含了各种加工特徵,如:孔、倒角、圆弧、凹槽、凸台,这些特徵非常精确,和实际加工特徵一样。

在Vericut 6.2里面,模型输出可以输出能够产生的特徵,单独的不能生成的特徵或不好的特徵(如球头刀生成的“凹坑”)可以输出综合特徵。

其他的增强功能使模型的表面和边界更光顺。

输出的文件使用NURBS修整曲线,减小了文件的大小。

CGTech VERICUT 8.x | 2.26 GbVERICUT 8.

0 features several enhancements designed to increase the ability of manufacturing engineers to analyze, optimize, and document the CNC programming and machining process.

Intelligence gathered from both the cut part and the machining process is applied to achieve an even higher level of accuracy and efficiency.

CGTech is increasingly challenged to simulate more complex processes and machines, while supporting “first part, good part” production goals.

VERICUT 8.

0 ties complex processes together with the ability to monitor and evaluate many potential problems in an efficient and consolidated method, thereby reducing the time spent in the programming and machining cycle.

New Ribbon BarVERICUT 8.

0 optimizes workflow and helps you find the functionality you need with minimal mouse clicks.

Upon upgrading to VERICUT 8.

0, the first thing you will notice is the new Ribbon Bar.

The Ribbon Bar allows you to quickly select the VERICUT function you want to use.

As you move from tab to tab, the Ribbon bar dynamically updates to show the options available for that tab.

Options are grouped by the function they perform within VERICUT.

The Ribbon Bar is highly customizable, but to ease the transition, a “VERICUT Classic” setting organizes all of the menus and options where you previously found them (a “cheat sheet” is also available from the cgtech.

com website).

Several other layout options are included and can be selected depending on the task at hand.

Users can also create and save their own workflow as needed for different jobs.

“Air Cut” optimization built-inYou now have the ability to optimize “Air Cuts Only” (off-part milling cutter motions) as a capability included with VERICUT’s base Verification license.

The new method is intended as an easy-to-use, entry level method of optimizing NC programs.

Additional optimization strategies are available with the purchase of OptiPath or FORCE.

Read STEP files – no extra license requiredThe STEP Model Interface reads STEP files (.

stp or .

step) containing AP203 and AP214 (geometry only) protocols.

A STEP file can be referenced directly in VERICUT’s modeling interface to describe machine, stock, fixture, and design shapes, or 3D cutting tool shapes in VERICUT’s Tool Manager.

The Tool Manager displays the CAD Geometry window that allows you to identify which parts of the CAD model file correspond with holders, cutters, or inserts.

Integration with cutting tool suppliers and tool management systemsAs with all software programs, the accuracy of the data input will directly affect the output.

So, an accurate model of the cutting tool and holder is required for the effective and accurate simulation of the machining process.

Most leading cutting tool manufacturers now make 3D solid model data available and VERICUT can read in this model data for use in the simulation process.

Many of the 3D models are available via the Machining Cloud App, and version 8.

0 has been enhanced to take advantage of more Machining Cloud metadata.

This can significantly simplify the configuration of tools for use in VERICUT, and better describe their proper use and limitations.

VERICUT also integrates with most major tool management systems.

Pre-setting suppliers including Zoller and Speroni can also interface to the software, so tool offsets and exact dimensions can be applied to the simulation session.

Tool Manager preferencesA new preferences dialog allows users to setup many default settings that help to streamline creation of cutting tool assemblies.

For example, you can specify the colors used, and the driven point offset numbering scheme (default to “1”, or follow the tool number), and CAD model tolerances for cutters and holders, and if holder is desired (or not) for a new tool.

Each imported 3D tool model can also have its own separate model tolerance.

For example, you may want a very high accuracy on the cutter model, and less tolerance on the holder model.

Version 8.

0 Tool Manager has a number of other time-savers, such as being able to mark any tools as “Default”, to be the starting point for building similar tools of that type, instead of starting from scratch.

There are also a number of Copy/Paste/Multi Select improvements.

Consolidated reporting featuresThe VERICUT logger now displays messages and reports from many sources in a tabbed logger window.

In addition to errors, warnings, and other messages from the VERICUT session, it also displays information from AUTO-DIFF and X-Caliper.

The messages can be grouped, sorted, and displayed in a variety of ways depending on user preference.

VERICUT speeds investigation with dynamic links between logger messages and responsible NC Program records.

The exact source of an error is just one click away.

Graphical tool path analysisA new “Toolpath Trace” feature creates a wireframe of the motion path that can then be measured.

In NC Program Preview or Review modes, picking on a toolpath trace in the wireframe automatically sets the simulation to that record in the NC program.

Force enhancementsThe Force module, first available with the release of version 7.

4, is a physics-based optimization method that determines the maximum reliable feedrate for a given cutting condition based on four factors: force on the cutter, spindle power, maximum chip thickness, and maximum allowable feedrate.

In version 8 there are new features for better control of entry/exit speeds, “clean-up” feedrates, and tooling information has been re-arranged to be more intuitive.

Other new features not to miss:- Translate models via selecting solid model features, eliminating the need to create coordinate systems for positional information.

- Enhanced modeling options provide greater control and flexibility over moving individual models, assemblies, and component origins, greatly reducing time to model machines, especially from 3D CAD model assemblies.

- Many performance enhancements.

- New method to compare the stock cutting position to a 2D DXF file drawn for design.

- Launch WinTool interface from within Tool Manager.

- Windows 10 is supported.

- Self-guided training sessions launch from the welcome screen and automatically open the associated sample files.
