自动化软件供应商EPLAN的EEC One产品已经能够支持平台全部的17种语言。新集成的词典功能可以确保直接访问EPLAN词典库，因此原理图中所有的文档文本都可以被翻译成所需的语言。同时它也确保了在描述中使用统一的术语、短语或特殊字符保持一致性。消除了语言切换障碍，提高了软件使用的效率水平，尤其让在多个国家开展业务的国际公司受益匪浅。

Excel环境的自动化

高效的工程设计不仅体现在流程的合理化和设计的自动化，更加体现在软件应用的用户友好性上。同时，EPLAN继续使用久经考验的Excel环境来运行EEC One，带来更直观的用户体验。新的色彩应用支持错误检索功能。此外，在当前版本的宏可以比先前版本的宏做到更快速应用和更清晰的定位。

EPLAN平台的完美集成

EEC One和EPLAN平台在部件选择上也做到了的无缝集成。现在EEC One可以直接调用EPLAN的部件库，并且能传输部件数据和参考数据。因为使用了自动传输，数据的传输误差可以有效避免，同时效率进一步得到提升。并且，新版本的EEC One同时支持EPLAN平台当前的2.3版本和先前的2.2版本。

自动化第一阶段

如今，设计效率不再像以前一样，只是额外考虑的价值。对大多数公司而言，如果想在国内和国际都保持成功，它是必不可少的关键因素。在实现高效工程设计的进程中，软件工具能够帮助用户从日常任务中解脱，它体现了重要的价值。这节省了更多的时间用于创新研发和解决问题。在EPLAN平台上，基于宏技术已经可以为标准化设计提供选择配置，而通过EEC One可以更直接的自动生成电气和流体液压设计的原理图。

EPLAN

P8 EEC One 2.6 | 606.4 mb

EPLAN Software & Service GmbH & Co., a provider software for global engineering solutions, has released 2.6 version of EPLAN Platform P8. With the new EPLAN Platform, version 2.6, users benefit from substantial engineering features that can easily be integrated into everyday work processes, including new functions for terminal design and project data management, the representation of piping in fluid power engineering, and optimised IT integration.

English, German, Japanese and Chinese: EPLAN software previously ‘spoke’ just seventeen languages. With the new version 2.6, Turkish has been added to the software languages – after all, EPLAN has been running its own affiliate company in Istanbul since 2014. There are also numerous technical upgrades in the newest version. Used accessories can now easily be depicted when processing and managing terminal strips. Furthermore, automatically or manually defined jumpers can also be easily identified. Users also have the possibility to display the current terminal status as it is represented in the Navigator. Yet another improvement: a new connection-oriented view quickly shows which terminal connections are still free and therefore available. Aside from these functionalities making designing simpler, they also significantly accelerate design engineering processes.

Managing Projects and Project Data

Using the Quick Input Filter for project management makes it even easier to process and manage projects and project data. Subprojects are freely definable and can be saved at will, and there is more flexibility in name allocation. For instance, users can only update the main project instead of storing subprojects with the goal of bringing the main project up to date. In project structure management, certain structures can be searched for and revised throughout the entire project, which considerably simplifies project oversight. The definition of sequencing pages for print or PDF outputs has also been appreciably enhanced – and users also benefit from faster results in this area.

Piping/Hose Lines in 3D

For hydraulics and pneumatics, for cooling and lubrication: numerous applications require the use of pipes or hose lines to transport media such as air or oil. EPLAN Fluid Professional, including the EPLAN Pro Panel add-on, now offers the possibility to represent piping and hydraulic hose lines directly in 3D with complete layout functionality. Design engineers can thus review the layout or for instance the length of the hose lines. An export function is also provided in order to transfer the pipe geometries to an external manufacturing software for pipe bending.

From Preplanning to Detail Engineering

Many new functions were optimised to simplify integrating EPLAN Platform into customers’ existing processes. EPLAN Preplanning now allows data from external sources to be imported. A preview function allows incoming data to be verified before being imported. Differences are easy to recognise and even previously deleted objects can now easily be found and removed from preplanning and detail engineering. This represents the next step toward more data consistency and data continuity within design engineering – from preplanning through to detail engineering.

Better IT Integration

User management has also become easier: existing users can simply be imported into an IT infrastructure instead of having to create a new user. EPLAN user rights management was expanded with support for Active Directory. The use of SQL databases has also been made simpler: a selection list of available SQL databases is available from which to select the correct one.

About EPLAN EEC One

The use of EPLAN Engineering Configuration One (EEC One) is the first step on the road towards automation. In electrical and fluid engineering pre-defined standards such as circuit board elements or value sets are automatically collated into a wiring diagram based on Excel, thus simplifying machine design. In control cabinet and switchgear engineering, in EEC One combined with EPLAN Pro Panel, predefined 3D assembly layouts and more flexible control systems have reduced the time needed for the virtual configuration and assembly of mounting levels in control cabinets. Customers striving to standardise processes and data in engineering will benefit from this automation over the long term.

About EPLAN Software & Service GmbH & Co.

At EPLAN, we have been developing electrical CAD software for 30 years. As a subsidiary of Rittal within the Friedhelm Loh conglomerate, we are aim to provide users with efficient engineering solutions to enhance their electrical design. With a presence in over 50 countries across the globe, a professional electrical engineering consultancy service is always close to hand, regardless of your companies location. More than 40,000 customers-from international firms to sole traders, throughout a range of industries, are using our electrical CAD solutions to enhance their electrical design processes.

Product:

EPLAN P8 EEC One

Version:

2.6.3.10395

Supported Architectures:

64bit

Website Home Page :

http://www.eplan.de

Language:

multilanguage

System Requirements:

PC

Supported Operating Systems:

Windows 7even / 8.x / 10

Software Prerequisites:

HERE

Size:

606.4 mb
