CAMWorks

2017 for Solid Edge最新发布！

CAMWorks for Solid Edge 是一款完全集成在 Solid Edge 中的嵌入式 CAM 程序。 它是市场上唯一一款基于特征的 CAM 产品，采用同步建模技术，可为用户提供前所未有的优势，例如：

利用自动特征识别功能和知识库，将编程时间从数小时缩短为几分钟。

利用自动特征识别功能并通过专有的技术数据库指定适当的加工策略，保留并建立标准的制造最佳实践。

易于学习和使用，有助于降低拥有成本。

自动重新生成刀具轨迹，快速对任何 CAD 模型“动态”应用制造设计变更，有助于缩短周转时间。

以性能超高的刀具轨迹缩短加工时间。

CAMWorks 2017 SP0 for Solid Edge | 1.7 Gb

Geometric Americas, Inc released CAMWorks 2017 with significant additions to the software focusing on customer needs and worldwide manufacturing initiatives, such as Smart Manufacturing and Industrie 4.0. The new capabilities in CAMWorks 2017 are a result of more than 60 customer-driven enhancements.

Some of the most significant enhancements to CAMWorks 2017 include:

Tolerance Based Machining (TBM)

– Uses tolerances and non-geometric data in a 3D CAD model to select optimal machining strategies and create toolpaths automatically. CAMWorks unique TBM capability leverages SOLIDWORKS MBD and DimXpert information to read annotations from a SOLIDWORKS 3D model and use the annotations to, automatically selects the tools, feed and speed required to develop optimal toolpaths. TBM can increase productivity by as much as 70% or more over traditional CNC programming methods while providing the ability to capture and re-use best practices. It also improves quality by automatically selecting the best machining strategy to meet the required quality requirements. CAMWorks High Speed Machining, VoluMill Milling Advisor – Provides recommended feed and speed parameters to maximize the performance of VoluMill high-speed machining.

Chuck and Fixture Definition

– Provides the ability to use chucks and fixtures designed using SOLIDWORKS parts and assemblies or STL files for toolpath simulation and collision detection in Mill-Turn and Turning. The chucks and fixtures can be moved or rotated in x, y, and z directions with respect to the Fixture Coordinate System (FCS) of the current part, ensuring that the chuck or fixture is properly aligned with the current part. SOLIDWORKS configurations of the chucks and fixtures are also supported.

3D Interconnect in SOLIDWORKS and CAMWorks Solids

– Provides a continuous path of associativity from 3D model changes in all leading 3D CAD formats through automatic updating of toolpaths that dramatically speeds up re-programming as parts change.

SOLIDWORKS Integration

– Tighter integration with SOLIDWORKS ensures that the design and manufacturing models are one and the same. SOLIDWORKS and CAMWorks are fully associative in all aspects including API Automation with SOLIDWORKS partner products such as DriveWorks, Configurations, MBD, and DimXpert annotations, meaning that any change made to a 3D model in SOLIDWORKS on the design side will automatically be reflected in CAMWorks on the manufacturing side. With this strong connection, machining strategies in CAMWorks are based on annotations from the MBD data provided by DimXpert in SOLIDWORKS. 3D Interconnect in SOLIDWORKS provides associativity to all major CAD formats, from geometry level changes through toolpath generation, dramatically reducing CNC re-programming efforts.

Product:

CAMWorks

Version:

2017 SP0 (build 2016/1214)

Supported Architectures:

64bit

Website Home Page :

http://www.camworks.com

Language:

multilanguage

System Requirements:

PC

Supported Operating Systems:

Windows 7even / 8.x / 10

Software Prerequisites:

Solid Edge ST8 МР05 and above / Solid Edge ST9 МР00 and above

Size:

1.7 Gb
