nestingworks为SolidWorks提供了自动套料和嵌套的解决方案，nestingworks是一款自动套料软件，被设计用于嵌套Solidworks零部件或装配体的布局。可以与Solidworks无缝集成，允许三维钣金零部件平板特征和装配体模型的套料，nestingworks采用的是NestLib技术，是工业界一种最快和最具特色的真实形状套料库。该插件可被用于金属、木材或复合材料高效的排版布局，单位时间内可生产出最大数量的零部件。

Geometric

NestingWorks

2017 SP0.0 | 102.9 mb

Geometric Ltd., a global leader in 3D CNC machining software, announced the release of NESTINGWorks 2017 3D nesting software for automatically nesting layouts of SOLIDWORKS parts and assemblies for production. This 3D nesting application is seamlessly integrated within SOLIDWORKS software, enabling automated nesting of flat or 3D part or assembly models made from sheet stock, including sheet metal, plates, plastics, composites, or wood.

NESTINGWorks software leverages Geometric’s industry-leading NESTLib true-shape 3D technology—known to nesting application developers worldwide as one of the fastest and most fully featured automatic true-shape nesting libraries available in the industry. With NESTINGWorks, product designers can efficiently optimize sheetstock layouts—including specifications for grain direction—so they can produce the maximum number of parts from a single piece of raw material in a matter of minutes, saving time, while simultaneously minimizing material usage.

Unlike other nesting applications that use 2D layouts, NESTINGWorks software provides 3D true-shape layouts, which lets designers nest parts of varying thicknesses. The solution is also compatible with all downstream machining and manufacturing applications. Combined with SOLIDWORKS design configuration tools, designers can use NESTINGWorks to nest multiple sets of assembly and or part variants, from a single SOLIDWORKS model.

Bug Fixes in NESTINGWorks 2017 SP0:

CWNEST-1073 Texture is not detected for the attached customer part.

CWNEST-1083 Application crashes when user executes Create Nest Job Command from the NESTINGWorks menu for an assembly.

CWNEST-1071 Add default parameter in INI file for the grain direction.

CWNEST-1085 Part Texture angle is not updated for different Texture part.

About Geometric

Geometric is a specialist in the domain of engineering solutions, services and technologies. Its portfolio of Global Engineering services, Product Lifecycle Management (PLM) solutions, Embedded System solutions, and Digital Technology solutions enables companies to formulate, implement, and execute global engineering and manufacturing strategies aimed at achieving greater efficiencies in the product realization lifecycle.

Product:

Geometric NestingWorks

Version:

2017 SP1.0 Build 2017/0117

Supported Architectures:

64bit

Website Home Page :

http://www.camworks.com

Language:

english

System Requirements:

PC

Supported Operating Systems:

Windows 7even SP1 / 8.x / 10

Software Prerequisites:

SOLIDWORKS 2016 SP4 or higher version

Size:

154.5 mb
