FINE/Open

：非结构网格CFD 求解器。该模块的独特性在于：她所采用的网格全是六面体的非结构网格（这是目前最先进的方法之一）；自动自适应的多重网格求解器。

FINE

TM

/Open

软件通过求解基于密度的全可压缩三维雷诺平均NS方程来模拟流场，广泛用于各种低速、亚音速、跨音速、超音速及高超音速流动的模拟。该软件拥有先进的前后处理模块、丰富的湍流模型，先进的全多重网格加速技术Agglomeration及强化隐式加速收敛技术CPU Booster等创新性技术，使其在行业内具有明显的优势。

特点：

针对复杂几何（包括旋转机械）与AutoGrid

TM

分块结构化网格的完全兼容性

全二阶精度空间/时间离散格式

多种湍流模型（S-A, SARC, K-e和SST）以及LES、DES等

Agglomeration全多重网格加速技术，比采用传统的Hierachy方法速度提高约4-8倍

CPU Booster强化隐式加速收敛技术、可将CFL数推至1000

流程自适应求解技术

先进的低速预处理方法

常用的流体物性数据库以及用户自定义功能

MpCCI流固耦合分析模块

共轭传热/燃烧/多孔介质模块

强大的TaskManager多任务管理功能

优秀的并行加速功能

自动化和集成化的后处理，CFView

TM

应用

FINE

TM

/Open 覆盖了大量的应用领域，如飞行器（包括附体），旋转机械（涡轮叶片冷却）、汽车空气动力学和环境流动等。

NUMECA

FINE/Open 3.1-x | 4.4 Gb

FINE/Open with OpenLabs is a powerful CFD Flow Integrated Environment dedicated to complex internal and external flows. FINE/Open with OpenLabs solves any flow, from incompressible to low and high speed flows. It combines completely unstructured hexahedral grids with an efficient preconditioned compressible solver with fast agglomerated multigrid acceleration and adaptation techniques.

FINE/Open with OpenLabs allows users to freely develop and exchange physical models in CFD, with a new open approach to CFD. Complex programming tasks are avoided through the usage of an easy meta-language.

HEXPRESS:

- Full Hexahedral Grids (no prism, no tetrahedra, no pyramid)

- Direct CAD import capabilities

- CAD manipulation and decomposition tools

- Mesh wizard for rapid solution set-up and easy back and forth operation

- Buffer cell and boundary layer insertion for high quality cells in boundary layer regions

- Automatic refinement procedures based on user defined sensors either next to solid walls or at specified area in the domain

- Multi domain capabilities allowing the treatment of CHT and multi-part geometry models

- Full non-matching multi-block connection, allowing multi-row turbomachinery meshing

FINE/Open flow solver:

- One single code for all types of fluids (incompressible, low-compressible, condensable and fully compressible) and speed (low speed to hypersonic regime)

- Acceleration with the CPUBooster module provides 3-5 times gain in convergence speed

- Embedded fluid structure interaction with the Modal and Flutter Analysis module

- Multigrid convergence acceleration

- Full Non-Matching Boundaries capability

- Cavitation

- Python scripting technology

OpenLabs:

- OpenLabs allows users to customize or add physical models

- Flexible and user-friendly Graphical User Interface

- Users don’t need to care about programming details and code structure

- OpenLabs can be used in a wide variety of industrial and academic applications

- Identical computing and memory costs compared to source-coded models

- Free access to all FINE™/Open community

CFView:

- Multi-projects and multi-views graphical user interface

- Python scripting technology

About Numeca International Inc.

NUMECA International is a worldwide provider of computational fluid dynamics (CFD) software and consulting services. NUMECA software is used for the simulation, design, and optimization of fluid flow and heat transfer. It is used by product developers, design, and research engineers, allowing them to reach superior product quality and performances at a reduced engineering cost.

NUMECA International's corporate headquarters are located in Brussels, with offices, resellers, and service centers in Brazil, China, Germany, India, Japan, Korea, Russia, Spain, and the USA. The company won the "Grand Prix Entreprendre 2000" from the Brussels Chamber of Commerce and Industry for its success in exporting high tech products worldwide.

Name:

Numeca FINE/Open

Version:

3.1-3

Home:

www.numeca.com

Interface:

english

OS:

Windows 7 / 8 and Linux 64bit

Size:

4.1 Gb

Special Thanks SSQ & RG Engineer

Numeca FINE/Open 3.1-3 Win/Linux
