LMS Samtech Tea Pipe

是一款全新的综合性软件包，用于对多种软管、线缆和管路（例如汽车的制动拉索或发动机周围的气管和水管）进行机械非线性仿真分析。

对设计师和工程师而言，设计灵活的软管、管路或线缆具有一定的挑战性，设计不当可能导致后续产品召回，造成重大损失。通过由新版LMS Samtech Tea Pipe软件驱动的、基于 CAE的设计流程，在决定创建成本高昂的原型机之前，用户可以事先对安装问题、碰撞、软管的曲率以及扭转弯曲等问题进行仿真分析。同时，控制管路设计的扭力对避免由疲劳引起的问题同样至关重要。

LMS

Samtech Tea Pipe软件可以单独使用，也可以作为NX 9或更高版本NX软件的嵌入式工具。通过无缝导入NX Motion模块的结果、对安装管路的子系统的运转进行计算等功能，用户可以对所有运动位置下的管路形状进行仿真分析，这样便可形成一个完整的环境，将管路和软管仿真整合入基于CAE的设计流程。利用LMS Samtech Tea Pipe软件，一家大型汽车OEM曾将制动拉索的设计时间从数周减少至短短数天。

Siemens

LMS Samtech Tea Pipe 17.1 rev.1138 | 1.1 Gb

LMS, which was acquired by Siemens in January 2013 and is now a business segment within Siemens PLM Software, has released 17.1 rev.1138 version of LMS Samtech Tea Pipe, is a comprehensive and powerful software package for the mechanical nonlinear simulation analysis of many types of hoses, cables and pipes (such as brake cables in a car or air and water hoses around a motor). As an LMS Tea Pipe user, you can analyze the behavior of pipes within a Siemens PLM Software NX or CATIA® V5 environment.

With LMS Tea Pipe, you can use a pipe manufacturer database to define material behavior as well as define pipe connectors and supports on points and geometries from CAD models. You can find the optimal length, the connector positions and orientations while checking collisions or curvatures. As a result, you can export deformed pipes to create a new pipe shape and use the input for further analysis.

LMS Tea Pipe calculations account for:

- Nonlinear geometrical behavior of pipes

- Vulcanization process of preshaped hoses

- Wheel rotations and translations

- Dynamics such as inertia and damping

LMS Tea Pipe benefits from advanced visualization tools of NX/CATIA V5, allowing efficient and straightforward preprocessing and postprocessing of nonlinear mechanical analysis. The results include deformed mesh, nodal normal distance, curvature, force, moment and successive configurations.

About LMS

LMS is a leading provider of test and mechatronic simulation software and engineering services in the automotive, aerospace and other advanced manufacturing industries. As a business segment within Siemens PLM Software, LMS provides a unique portfolio of products and services for manufacturing companies to manage the complexities of tomorrow’s product development by incorporating model-based mechatronic simulation and advanced testing in the product development process. LMS tunes into mission-critical engineering attributes, ranging from system dynamics, structural integrity and sound quality to durability, safety and power consumption. With multi-domain and mechatronic simulation solutions, LMS addresses the complex engineering challenges associated with intelligent system design and model-based systems engineering. Thanks to its technology and more than 1250 dedicated people, LMS has become the partner of choice of more than 5000 manufacturing companies worldwide. LMS operates in more than 30 key locations around the world.

Product:

Siemens LMS Samtech Tea Pipe

Version:

17.1 rev.1138

Supported Architectures:

x64

Website Home Page :

http://www.plm.automation.siemens.com

Language:

english

System Requirements:

PC

Supported Operating Systems:

Windows XP / Vista / 7even / 8.x / 10

Software Prerequisites:

DS CATIA V5 R19-R25

Size:

1.1 Gb
