计算机仿真技术公司（

CST

）欣然宣布2017年版其旗舰的电磁仿真软件CST

STUDIO SUITE

。

CST STUDIO SUITE

2017多年的研究和发展，包括在各个层面的改进和创新，从优化求解技术新的功能区为基础的GUI。 这些进步提升CST STUDIO套件的性能，易用性和多功能性，毫不妥协，并引导您轻松通过复杂的电磁系统。

CST STUDIO SUITE被广泛应用在通信和电子医疗保健和航空等领域工作的工程师，帮助他们电磁现象的建模和评估他们的设计，以获得最佳性能。 结合高频和低频模拟工具以及专门求解器的应用，如印刷电路板，电缆和带电粒子设备，可以应用到许多典型的工程任务，如EMC / EMI评估，SI和PI的分析，设计CST Studio套件优化，天线及滤波器的调谐。

最明显的提高在2017年的版本是基于色带的用户界面。 功能区集中在标准模拟工作流程，领导工程师设置和建模仿真和后处理。 色带补充新的功能，包括项目向导和快速入门指南，编制和配置简单的一个新项目的过程中。

这些变化，幕后的技术改进。 通过科与英特尔的密切合作，求解器代码进行了优化，提高性能的最新一代处理器。

为了提高软件的通用性，CST STUDIO SUITE还包括全新的分析工具，，如汽缸扫描和范围配置正弦。 这些扩大，该软件可以被用于应用程序的数量，并允许它很容易插槽成许多不同的工作流程。

CST STUDIO SUITE 2017.01 | 3.2 Gb

Computer Simulation Technology (CST) has launched the 2017 version of its electromagnetic simulation tool, CST STUDIO SUITE. The latest edition includes a range of new tools for synthesis and analysis and improvements to existing features. It is now available to order globally.

The CST STUDIO SUITE is an electromagnetic (EM) simulation software package with solvers for various applications across the electromagnetic spectrum, as well as multi-physics and particle applications. All of CST tools are available within a single graphical user interface and can be linked together for straightforward hybridization of simulations. It is currently being used in leading companies across the high-tech and manufacturing industries to develop new ideas, optimize products, and ensure standards compliance. The 2017 release of the suite builds on the success of previous releases with new features for broader and more in-depth analysis of EM systems.

The new tool Filter Designer 3D (FD3D) can now automatically synthesize cross-coupled and diplexer filter designs to meet the specifications, including transmission zeroes, Q-factor, and equiripple. The complex and sensitive nature of these filters makes them challenging to design and tune with traditional methods. Coupling matrix extraction with FD3D offers an efficient way to fine-tune 3D filter structures.

The new Interference Task offers a straightforward approach for investigating potential EMI issues using coupling data from simulations. At a glance, it shows which combinations of RF systems can potentially lead to co-site interference problems, allowing mitigation approaches to be tested on a virtual prototype. The updated ray-tracing Asymptotic Solver in STUDIO SUITE can now directly calculate the coupling between antennas. It can simulate extremely large platforms such as aircraft, ships, and buildings very efficiently, making it well suited to many kinds of antenna placement scenarios. This can be combined with the Interference Task for detailed co-site analysis of vehicles, vessels, and aircraft.

The 2017 version also sees the expansion of CST MPHYSICS STUDIO tools with the Conjugate Heat Transfer (CHT) Solver. This uses Computational Fluid Dynamics (CFD) to simulate the flow of air through devices, taking fans and vents into account. With the CHT Solver, users can include the cooling systems in their multi-physics simulation, allowing these systems to be designed and optimized before constructing prototypes.

About CST Computer Simulation Technology AG.

Founded in 1992, CST offers the market’s widest range of 3D electromagnetic field simulation tools through a global network of sales and support staff and representatives. CST develops CST STUDIO SUITE, a package of high-performance software for the simulation of electromagnetic fields in all frequency bands, and also sells and supports complementary third-party products. Its success is based on combination of leading edge technology, a user-friendly interface and knowledgeable support staff. CST’s customers are market leaders in industries as diverse as telecommunications, defense, automotive, electronics and healthcare. Today, the company enjoys a leading position in the high-frequency 3D EM simulation market and employs 280 sales, development, and support personnel around the world.

Product:

CST STUDIO SUITE

Version:

2017.01

Supported Architectures:

x64

Website Home Page :

http://www.cst.com

Language:

english

System Requirements:

PC

Supported Operating Systems:

Windows 7even / 8.1 / 10 / Server 2012 R2

Size:

3.2 Gb
